70℃恒温湿漏电流测试绝缘水槽 (CAS No.None)

Product Name:70°C Constant Temperature Wet Leakage Current Insulation Water Tank

English Name:70°C Constant Temperature Wet Leakage Current Insulation Water Tank

Aliases:PV Module Wet Leakage Current Test Water Tank, KM-PV-WL Wet Leakage Current Test Water Tank

Physical Properties:The equipment consists of a test water tank, a heating water tank, and a constant temperature water tank. The test water tank measures 2100mm×1600mm×200mm and accommodates PV modules up to 2000mm×1500mm. The constant temperature water tank provides a temperature range from room temperature to +70°C. It is equipped with a submersible pump with a 10-meter head. The liquid resistivity is less than 3500Ω·cm, and the spray pressure is 34.5kPa. The overall weight is approximately 150kg, and the power requirement is single-phase AC220V±5%, 25A.

Uses:Used in PV module wet leakage current testing systems to evaluate the insulation performance of modules under damp working conditions. It effectively detects whether moisture from rain, fog, dew, or melting snow has penetrated into the active circuitry of the module, assessing potential risks of corrosion, leakage current, and safety hazards. Designed specifically for the solar PV module industry.

Technical Specifications:

Test water tank dimensions: 2100mm×1600mm×200mm

Constant temperature water tank range: room temperature to +70°C

Maximum detectable module size: 2000mm×1500mm

Liquid resistivity: <3500Ω·cm

Spray pressure: 34.5kPa
