标准风室 风量测试台 (CAS No.None)
- 物化性质
- 设备主体采用全不锈钢定制，双面无缝焊接处理，密闭性好，测量精度高；自动化程度高，各设备启停、工况和流量调节均自动完成，采用全自动喷嘴，根据测试风量自动选择，无需人工更换。
- 技术参数
- 风量测量范围210-30000m³/h，精度±1%。 功率测量范围30-8000W，精度±0.5%。 压差测量范围-50-500Pa，精度±0.075%。 温度测量范围-20-50℃，精度±0.1℃。
English description（英文原文，共 1349 字符）
Product Name:Air Volume Test Bench
English Name:Air Volume Test Bench
Aliases:Standard Air Chamber Air Volume Test Bench, Air Volume Testing Device
Physical Properties:The equipment body is made of stainless steel with double-sided seamless welding, good sealing and high measurement accuracy. It features high automation, with automatic start/stop, condition adjustment and flow regulation. Automatic nozzles are adopted to select the appropriate nozzle based on the test airflow rate without manual replacement.
Uses:This equipment is used to accurately measure the rated airflow of fans with air conditioner housings, as well as to determine the static pressure-dry air volume and power-dry air volume performance curves of fan coil units, small air handling unit axial fans, cross-flow fans, centrifugal fans and other fan types. It complies with GB/T 1236-2017 and meets the technical requirements for laboratory certification and production license applications.
Technical Specifications:
Air volume measurement range: 210-30000 m³/h, accuracy ±1%.
Power measurement range: 30-8000 W, accuracy ±0.5%.
Differential pressure measurement range: -50-500 Pa, accuracy ±0.075%.
Temperature measurement range: -20-50 ℃, accuracy ±0.1℃.
Implemented standard: GB/T 1236-2017 'Industrial fans - Performance testing using standardized airways'.
English Name:Air Volume Test Bench
Aliases:Standard Air Chamber Air Volume Test Bench, Air Volume Testing Device
Physical Properties:The equipment body is made of stainless steel with double-sided seamless welding, good sealing and high measurement accuracy. It features high automation, with automatic start/stop, condition adjustment and flow regulation. Automatic nozzles are adopted to select the appropriate nozzle based on the test airflow rate without manual replacement.
Uses:This equipment is used to accurately measure the rated airflow of fans with air conditioner housings, as well as to determine the static pressure-dry air volume and power-dry air volume performance curves of fan coil units, small air handling unit axial fans, cross-flow fans, centrifugal fans and other fan types. It complies with GB/T 1236-2017 and meets the technical requirements for laboratory certification and production license applications.
Technical Specifications:
Air volume measurement range: 210-30000 m³/h, accuracy ±1%.
Power measurement range: 30-8000 W, accuracy ±0.5%.
Differential pressure measurement range: -50-500 Pa, accuracy ±0.075%.
Temperature measurement range: -20-50 ℃, accuracy ±0.1℃.
Implemented standard: GB/T 1236-2017 'Industrial fans - Performance testing using standardized airways'.
