冰水冲击飞溅试验 (CAS No.None)
- 物化性质
- 设备用于模拟车辆浅水区域产品受到冰水溅射引起的热冲击工况，采用多翼离心式循环风扇送风系统，具备水平扩散垂直热交换弧形循环功能，配备无熔丝保护开关、机械式及电子式超温保护、缺水保护、冷冻压缩机过负载保护、电流超载保护、停电记忆保护及9点故障自诊显示等完善的安全保护装置。
English description（英文原文，共 1828 字符）
Product Name:Ice Water Impact Splash Test Chamber
English Name:Ice Water Impact Splash Test Chamber
Aliases:Ice water impact test chamber, Ice water splash test equipment
Physical Properties:The equipment simulates thermal shock caused by ice water splashing onto products in shallow water areas of vehicles. It features a multi-blade centrifugal circulating fan with horizontal air distribution and vertical heat exchange arc circulation. Comprehensive safety protections include fuse-free switches, mechanical and electronic over-temperature protection, water shortage protection, refrigeration compressor overload protection, current overload protection, power failure memory, and 9-point fault self-diagnostic display.
Uses:Designed to simulate thermal shock when ice water splashes onto heated systems or components during wet-road driving in winter. It evaluates mechanical cracking and seal failure caused by differing coefficients of thermal expansion, as well as seal degradation and water ingress into systems or components. Mainly applicable for reliability verification of electronic, electrical, and mechanical parts installed in shallow water areas of vehicles.
Technical Specifications:
Inner chamber dimensions: W1000×D1000×H1000mm; external dimensions approx. W1500×D1300×H1800mm; customizable.
Chamber temperature range: RT+10℃ to +150℃, temperature fluctuation ±0.5℃, temperature deviation ±2℃.
Test liquid: deionized water with 3% pure Arizona dust or 5% sodium salt; water temperature 0 to +4℃; water flow 3L-4L per 3 seconds.
Nozzle-to-DUT distance: 325±25mm; splash width always greater than DUT width; multiple nozzles can be arranged in a row.
Test cycles: 100; transition duration <20s; DUT orientation same as vehicle mounting direction; ambient test conditions +25℃, relative humidity ≤85%.
English Name:Ice Water Impact Splash Test Chamber
Aliases:Ice water impact test chamber, Ice water splash test equipment
Physical Properties:The equipment simulates thermal shock caused by ice water splashing onto products in shallow water areas of vehicles. It features a multi-blade centrifugal circulating fan with horizontal air distribution and vertical heat exchange arc circulation. Comprehensive safety protections include fuse-free switches, mechanical and electronic over-temperature protection, water shortage protection, refrigeration compressor overload protection, current overload protection, power failure memory, and 9-point fault self-diagnostic display.
Uses:Designed to simulate thermal shock when ice water splashes onto heated systems or components during wet-road driving in winter. It evaluates mechanical cracking and seal failure caused by differing coefficients of thermal expansion, as well as seal degradation and water ingress into systems or components. Mainly applicable for reliability verification of electronic, electrical, and mechanical parts installed in shallow water areas of vehicles.
Technical Specifications:
Inner chamber dimensions: W1000×D1000×H1000mm; external dimensions approx. W1500×D1300×H1800mm; customizable.
Chamber temperature range: RT+10℃ to +150℃, temperature fluctuation ±0.5℃, temperature deviation ±2℃.
Test liquid: deionized water with 3% pure Arizona dust or 5% sodium salt; water temperature 0 to +4℃; water flow 3L-4L per 3 seconds.
Nozzle-to-DUT distance: 325±25mm; splash width always greater than DUT width; multiple nozzles can be arranged in a row.
Test cycles: 100; transition duration <20s; DUT orientation same as vehicle mounting direction; ambient test conditions +25℃, relative humidity ≤85%.
