步入式恒温恒湿试验室DY-BRS-8G (CAS No.None)
- 中文别名
- 步入式恒温恒湿箱；大型恒温恒湿试验室
- 英文名称
- Walk-in Constant Temperature and Humidity Test Chamber (DY-BRS-8G)
- 所属类别
- 试剂实验设备
- 物化性质
- 外壁为优质彩钢板，内壁为304不锈钢板，保温材料为硬质聚氨酯泡沫+玻璃纤维；控制面板配有控制器显示屏、RS232电脑通讯接口、电源开关及状态指示灯；机械室含制冷机组、接水盘、排水孔、冷凝器机组；加热器为不锈钢铠装加热器，采用无触点等周期脉冲调宽SSR（固态继电器）控制；水位控制装置含加热器防干烧装置、沉淀物收集装置和液位观察窗；加湿方式为外置可拆卸锅炉加湿。
- 技术参数
- 标称内容积8立方米，内箱尺寸W2000×H2000×D2000mm，外形尺寸约W3700×H2300×D2300mm（高度不含马达）。 温度范围-40℃~+85℃，湿度范围30%~95%RH，均可调可恒定。 温度控制精度≤±0.5℃，温度波动度≤1℃，温度均匀度≤2.0℃；温湿度误差：温度≤±2℃、湿度≤±3%。 升温速率2℃/min（非线性空载可调），降温速率0.75~1℃/min（非线性空载可调）。 满足GB/T2423.1、GB/T2423.2、GB/T2423.3、GB/T2423.4及GJB150系列温湿度试验标准。
English description（英文原文，共 2029 字符）
Product Name:Walk-in Constant Temperature and Humidity Test Chamber (DY-BRS-8G)
English Name:Walk-in Constant Temperature and Humidity Test Chamber (DY-BRS-8G)
Aliases:Walk-in Temperature and Humidity Chamber, Large-scale Constant Temperature and Humidity Test Chamber
Physical Properties:The outer wall is made of quality color steel plate, and the inner wall is made of 304 stainless steel plate. The insulation material is rigid polyurethane foam plus glass fiber. The control panel is equipped with a controller display, RS232 computer communication interface, power switch and status indicator lights. The machinery room contains refrigeration unit, water receiving tray, drain hole and condenser unit. The heater is stainless steel armored heater with SSR (solid state relay) pulse-width modulation control. The water level control device includes heater dry-heating protection device, sediment collection device and liquid level observation window. Humidification adopts external detachable boiler humidification method.
Uses:Used for temperature and humidity environment testing of large electronic, automotive, rubber, plastic, aerospace and communication equipment products, to judge whether the reliability and stability of products are qualified, and to provide basis for predicting and improving product quality and reliability.
Technical Specifications:
Nominal interior volume: 8 m³; interior dimensions: W2000×H2000×D2000 mm; exterior dimensions approx.: W3700×H2300×D2300 mm (height excluding motor).
Temperature range: -40°C to +85°C; humidity range: 30%~95% RH; both adjustable and maintainable.
Temperature control accuracy: ≤±0.5°C; temperature fluctuation: ≤1°C; temperature uniformity: ≤2.0°C; temperature/humidity deviation: temperature ≤±2°C, humidity ≤±3%.
Heating rate: 2°C/min (nonlinear, no-load, adjustable); cooling rate: 0.75~1°C/min (nonlinear, no-load, adjustable).
Complies with GB/T2423.1, GB/T2423.2, GB/T2423.3, GB/T2423.4 and GJB150 series temperature and humidity test standards.
English Name:Walk-in Constant Temperature and Humidity Test Chamber (DY-BRS-8G)
Aliases:Walk-in Temperature and Humidity Chamber, Large-scale Constant Temperature and Humidity Test Chamber
Physical Properties:The outer wall is made of quality color steel plate, and the inner wall is made of 304 stainless steel plate. The insulation material is rigid polyurethane foam plus glass fiber. The control panel is equipped with a controller display, RS232 computer communication interface, power switch and status indicator lights. The machinery room contains refrigeration unit, water receiving tray, drain hole and condenser unit. The heater is stainless steel armored heater with SSR (solid state relay) pulse-width modulation control. The water level control device includes heater dry-heating protection device, sediment collection device and liquid level observation window. Humidification adopts external detachable boiler humidification method.
Uses:Used for temperature and humidity environment testing of large electronic, automotive, rubber, plastic, aerospace and communication equipment products, to judge whether the reliability and stability of products are qualified, and to provide basis for predicting and improving product quality and reliability.
Technical Specifications:
Nominal interior volume: 8 m³; interior dimensions: W2000×H2000×D2000 mm; exterior dimensions approx.: W3700×H2300×D2300 mm (height excluding motor).
Temperature range: -40°C to +85°C; humidity range: 30%~95% RH; both adjustable and maintainable.
Temperature control accuracy: ≤±0.5°C; temperature fluctuation: ≤1°C; temperature uniformity: ≤2.0°C; temperature/humidity deviation: temperature ≤±2°C, humidity ≤±3%.
Heating rate: 2°C/min (nonlinear, no-load, adjustable); cooling rate: 0.75~1°C/min (nonlinear, no-load, adjustable).
Complies with GB/T2423.1, GB/T2423.2, GB/T2423.3, GB/T2423.4 and GJB150 series temperature and humidity test standards.
