Clavis Type4声学式皮带张力计 (CAS No.None)
- 中文别名
- CLAVIS皮带张力仪 Type 4；Clavis Type4 声学皮带张力计
- 英文名称
- Clavis Type4 Acoustic Belt Tensiometer
- 所属类别
- 试剂实验设备
- 物化性质
- 采用CLAVIS专利声学传感器检测皮带振动信号，并最大限度降低环境噪音。支持不同宽度的传送带；配有精密机械谐振器（音叉）用于校准验证。操作由开/关键盘按钮控制，提供通用传感头，并可选购不同尺寸的可互换传感头。
English description（英文原文，共 1483 字符）
Product Name:Clavis Type4 Acoustic Belt Tensiometer
English Name:Clavis Type4 Acoustic Belt Tensiometer
Aliases:CLAVIS Type 4 Belt Tensiometer, Clavis Type4 Acoustic Belt Tension Meter
Physical Properties:Uses CLAVIS patented acoustic sensor to detect belt vibration signals while minimizing environmental noise. Supports conveyor belts of various widths; includes a precision mechanical resonator (tuning fork) for calibration verification. Operation is controlled by a simple on/off keypad button, with a universal sensing head supplied and interchangeable sensing heads of various sizes available on request.
Uses:Used for comparative belt tension checks by measuring belt vibration frequency acoustically. During measurement, the sensor jaw is positioned above the center of the belt span and must not contact the belt; typically two or three spans are selected for measurement. The span length must be defined because frequency depends on it, and longer spans vibrate more readily. If a belt tension adjuster is within the measuring range, ensure that the span length variation caused by the adjuster is not significant for consistent readings.
Technical Specifications:
Frequency range (acoustic): 30 to 600 Hz
Frequency range (optical): 10 to 600 Hz
Measurement accuracy: ±1 digit below 100 Hz; ±1% above 100 Hz
Operating temperature: +10 °C to +50 °C (+50 °F to +122 °F)
Protection rating: IP54; shipping and storage temperature: +5 °C to +70 °C (+23 °F to +158 °F)
English Name:Clavis Type4 Acoustic Belt Tensiometer
Aliases:CLAVIS Type 4 Belt Tensiometer, Clavis Type4 Acoustic Belt Tension Meter
Physical Properties:Uses CLAVIS patented acoustic sensor to detect belt vibration signals while minimizing environmental noise. Supports conveyor belts of various widths; includes a precision mechanical resonator (tuning fork) for calibration verification. Operation is controlled by a simple on/off keypad button, with a universal sensing head supplied and interchangeable sensing heads of various sizes available on request.
Uses:Used for comparative belt tension checks by measuring belt vibration frequency acoustically. During measurement, the sensor jaw is positioned above the center of the belt span and must not contact the belt; typically two or three spans are selected for measurement. The span length must be defined because frequency depends on it, and longer spans vibrate more readily. If a belt tension adjuster is within the measuring range, ensure that the span length variation caused by the adjuster is not significant for consistent readings.
Technical Specifications:
Frequency range (acoustic): 30 to 600 Hz
Frequency range (optical): 10 to 600 Hz
Measurement accuracy: ±1 digit below 100 Hz; ±1% above 100 Hz
Operating temperature: +10 °C to +50 °C (+50 °F to +122 °F)
Protection rating: IP54; shipping and storage temperature: +5 °C to +70 °C (+23 °F to +158 °F)
