带报警开关玻璃转子流量计 (CAS No.None)
- 中文别名
- 玻璃转子流量计；LZB/LZJ系列玻璃转子流量计；LZB-F/LZJ-F系列耐腐玻璃转子流量计
- 英文名称
- Glass Rotameter with Alarm Switch
- 所属类别
- 试剂实验设备
- 物化性质
- 产品由自下而上扩大的锥形玻璃管和浮子组成，流体自下而上流过时，浮子所受升力与浮力之和等于其重力时即稳定于某一高度，锥管刻度指示流量。可配备一个或两个报警开关，实现上下限报警。接液部件材质包括1Cr18Ni9Ti不锈钢、玛瑙、氟塑料、聚丙烯、黄铜、铸铁（内衬聚丙烯/氟塑料或涂防腐漆）等，密封件为丁腈橡胶或氟橡胶。
- 技术参数
- 通径范围DN4～DN150；DN4～DN10采用软管连接并配针形流量调节阀，DN15～DN150采用法兰连接，法兰标准GB/T9119-2000，公称压力PN0.6～1.0MPa。 可配备1个或2个报警开关，开关品牌可选欧姆龙或图尔克，起上下限报警作用。 LZB/LZB-F型锥管内壁光滑，通径DN15以上浮子由导杆导向；LZJ/LZJ-F型锥管内壁有三条导向凸筋，使浮子保持稳定。
English description（英文原文，共 2233 字符）
Product Name:Glass Rotameter with Alarm Switch
English Name:Glass Rotameter with Alarm Switch
Aliases:Glass Rotameter, LZB/LZJ Series Glass Rotameter, LZB-F/LZJ-F Series Corrosion-resistant Glass Rotameter
Physical Properties:The product consists of a tapered glass tube expanding upward and a float. When fluid flows upward through the tapered tube, the float rises until the sum of the dynamic lift and buoyancy equals its gravity, and the scale on the tube indicates the flow rate. It can be equipped with one or two alarm switches for high/low limit alarms. Wetted parts are made of 1Cr18Ni9Ti stainless steel, agate, fluoroplastic, polypropylene, brass, or cast iron (lined with polypropylene/fluoroplastic or coated with anti-corrosion paint), with NBR or FKM seals.
Uses:It is used in chemical, petroleum, light industry, pharmaceutical, environmental protection, food, metrology & testing, and scientific research sectors to measure the flow of single-phase non-pulsating liquids or gases. The alarm switch type can provide high/low limit flow alarms. The corrosion-resistant type can measure acids (except hydrofluoric acid), alkalis, oxidants, and other corrosive gases or liquids, and is suitable for chemical, pharmaceutical, papermaking, and wastewater treatment industries.
Technical Specifications:
Nominal diameter range DN4~DN150; DN4~DN10 use hose connection with needle flow control valve, DN15~DN150 use flange connection per GB/T9119-2000, with nominal pressure PN0.6~1.0MPa.
Can be equipped with 1 or 2 alarm switches, available in Omron or Turck brands, for high/low limit alarming.
LZB/LZB-F models have a smooth tapered tube inner wall, and the float is guided by a rod for DN15 and above; LZJ/LZJ-F models have three guide ribs on the inner wall to keep the float stable.
Wetted materials: float in 1Cr18Ni9Ti stainless steel, agate, or fluoroplastic-wrapped; base in HPb59-1 brass, 1Cr18Ni9Ti stainless steel, or cast iron (lined with polypropylene/fluoroplastic or anti-corrosion painted); seals in NBR or FKM.
Applicable to single-phase non-pulsating fluids (liquids or gases); corrosion-resistant type can measure acids (except hydrofluoric acid), alkalis, oxidants, and other corrosive media.
English Name:Glass Rotameter with Alarm Switch
Aliases:Glass Rotameter, LZB/LZJ Series Glass Rotameter, LZB-F/LZJ-F Series Corrosion-resistant Glass Rotameter
Physical Properties:The product consists of a tapered glass tube expanding upward and a float. When fluid flows upward through the tapered tube, the float rises until the sum of the dynamic lift and buoyancy equals its gravity, and the scale on the tube indicates the flow rate. It can be equipped with one or two alarm switches for high/low limit alarms. Wetted parts are made of 1Cr18Ni9Ti stainless steel, agate, fluoroplastic, polypropylene, brass, or cast iron (lined with polypropylene/fluoroplastic or coated with anti-corrosion paint), with NBR or FKM seals.
Uses:It is used in chemical, petroleum, light industry, pharmaceutical, environmental protection, food, metrology & testing, and scientific research sectors to measure the flow of single-phase non-pulsating liquids or gases. The alarm switch type can provide high/low limit flow alarms. The corrosion-resistant type can measure acids (except hydrofluoric acid), alkalis, oxidants, and other corrosive gases or liquids, and is suitable for chemical, pharmaceutical, papermaking, and wastewater treatment industries.
Technical Specifications:
Nominal diameter range DN4~DN150; DN4~DN10 use hose connection with needle flow control valve, DN15~DN150 use flange connection per GB/T9119-2000, with nominal pressure PN0.6~1.0MPa.
Can be equipped with 1 or 2 alarm switches, available in Omron or Turck brands, for high/low limit alarming.
LZB/LZB-F models have a smooth tapered tube inner wall, and the float is guided by a rod for DN15 and above; LZJ/LZJ-F models have three guide ribs on the inner wall to keep the float stable.
Wetted materials: float in 1Cr18Ni9Ti stainless steel, agate, or fluoroplastic-wrapped; base in HPb59-1 brass, 1Cr18Ni9Ti stainless steel, or cast iron (lined with polypropylene/fluoroplastic or anti-corrosion painted); seals in NBR or FKM.
Applicable to single-phase non-pulsating fluids (liquids or gases); corrosion-resistant type can measure acids (except hydrofluoric acid), alkalis, oxidants, and other corrosive media.
