DG09-D液体持续燃烧试验仪 (CAS No.None)

Product Name:DG09-D Liquid Sustained Combustion Tester

English Name:DG09-D Liquid Sustained Combustion Tester

Aliases:Sustained Combustion Tester

Uses:This instrument is used to determine whether a substance will sustain combustion when heated and exposed to a flame under test conditions. It is suitable for the sustained combustion test of flammable liquids in dangerous goods, in accordance with the UN Recommendations on the Transport of Dangerous Goods, Manual of Tests and Criteria, Test L.2 (32.5.2) and GB/T 21622-2008.

Technical Specifications:

Operating environment: temperature -5°C to 45°C, relative humidity <95%RH.

Atmospheric pressure measurement range: 60~110kPa, accuracy ±0.25% F·S; temperature control range: room temperature +5~100°C, accuracy ±0.5°C; standard test temperatures: 60.5°C, 75°C.

Sample injection volume: 1~5mL, accuracy ±0.03mL; timing range: 0~999s, accuracy ±0.01s.

Electronic ignition, integrated near-infrared array sensor; automatically performs ignition, positioning, timing, data recording and result judgment.

Instrument dimensions: 570mm×350mm×350mm; equipped with 10.1-inch capacitive touch screen, supports one-click Excel test report export and face/account-password dual authentication login.
