低温恒温水槽 (CAS No.None)

Product Name:Low Temperature Thermostatic Water Bath

English Name:Low Temperature Thermostatic Water Bath

Aliases:Low Temperature Constant Temperature Water Bath, Vertical Low Temperature Thermostatic Bath

Physical Properties:Vertical design, adopting fluorine-free refrigeration technology, with both heating and cooling functions. The fully sealed imported refrigeration compressor has multiple protections including overheat, overcurrent, and overpressure. The circulating pump supports internal and external circulation, allowing the bath medium to be externally led to establish a secondary constant-temperature field. PID temperature setting program and high-precision temperature sensor are adopted for high control accuracy. The inner tank is made of S304 stainless steel, with a drain valve on the side for convenient medium replacement.

Uses:Widely used in research departments, universities, enterprise quality inspection and production departments in fields such as petroleum, chemical industry, electronic instrumentation, physics, chemistry, bioengineering, medicine and health, life sciences, light industry and food, physical property testing, and chemical analysis. It can be used as a direct heating or cooling source, and can also provide auxiliary temperature control for reactors, automatic synthesizers, extraction and condensation devices.

Technical Specifications:

Temperature range: -30°C to 100°C; different models cover -5 to 100°C, -10 to 100°C, -20 to 100°C, and -30 to 100°C respectively.

Temperature fluctuation: ±0.05°C (±0.1°C for -30°C models).

Temperature control accuracy: 0.01°C (0.1°C for -30°C models).

Circulating pump flow rate: 6 L/min or 13 L/min depending on model.

Working tank volume: multiple specifications from 250×200×150mm to 420×330×230mm; tank opening: 180×140mm, 235×160mm or 310×280mm; all models equipped with drain valve.
