电池组件实验室层压机 (CAS No.None)
- 中文别名
- 光伏实验室层压机；太阳能电池组件层压机
- 英文名称
- Laboratory Laminating Machine for Battery Components
- 所属类别
- 试剂实验设备
- 物化性质
- 该设备为光伏实验室用层压机，用于单晶硅、多晶硅及钙钛矿太阳能电池组件的封装。采用平面式层压平台、后双臂关盖结构及新型板式加热方式，配合西门子PLC控制与多点PID温控，可自动完成加热、抽真空、层压等过程，整个层压过程不超过15分钟。
English description（英文原文，共 1372 字符）
Product Name:Laboratory Laminating Machine for Battery Components
English Name:Laboratory Laminating Machine for Battery Components
Aliases:Photovoltaic Laboratory Laminator, Solar Cell Module Laminator
Physical Properties:This equipment is a laboratory laminator for photovoltaic use, designed for encapsulation of monocrystalline silicon, polycrystalline silicon, and perovskite solar cell modules. It features a flat laminating platform, rear dual-arm lid structure, and new plate heating method, with Siemens PLC control and multi-point PID temperature control, automatically completing heating, vacuuming, and lamination processes. The entire lamination process takes no more than 15 minutes.
Uses:Mainly used for encapsulation of monocrystalline, polycrystalline, and perovskite solar cell modules. It automatically performs heating, vacuuming, and lamination according to set programs, suitable for small-batch module preparation and process research in photovoltaic laboratories.
Technical Specifications:
Dimensions: 1250×1150×1250 mm
Lamination area: 700×700 mm; heating plate area: 850×850 mm
Temperature control range: room temperature to 200°C; working temperature: 100-160°C; temperature uniformity: ≤±2°C
Working vacuum: 20-200 Pa; pumping speed: 8-15 L/s
Total power: 5.5 kW; power supply: AC380V three-phase four-wire; total weight: approx. 0.8T
English Name:Laboratory Laminating Machine for Battery Components
Aliases:Photovoltaic Laboratory Laminator, Solar Cell Module Laminator
Physical Properties:This equipment is a laboratory laminator for photovoltaic use, designed for encapsulation of monocrystalline silicon, polycrystalline silicon, and perovskite solar cell modules. It features a flat laminating platform, rear dual-arm lid structure, and new plate heating method, with Siemens PLC control and multi-point PID temperature control, automatically completing heating, vacuuming, and lamination processes. The entire lamination process takes no more than 15 minutes.
Uses:Mainly used for encapsulation of monocrystalline, polycrystalline, and perovskite solar cell modules. It automatically performs heating, vacuuming, and lamination according to set programs, suitable for small-batch module preparation and process research in photovoltaic laboratories.
Technical Specifications:
Dimensions: 1250×1150×1250 mm
Lamination area: 700×700 mm; heating plate area: 850×850 mm
Temperature control range: room temperature to 200°C; working temperature: 100-160°C; temperature uniformity: ≤±2°C
Working vacuum: 20-200 Pa; pumping speed: 8-15 L/s
Total power: 5.5 kW; power supply: AC380V three-phase four-wire; total weight: approx. 0.8T
