电拉试验机 (CAS No.None)

Product Name:Electronic Tensile Testing Machine

English Name:Electronic Tensile Testing Machine

Aliases:Electronic Universal Testing Machine, Electronic Tensile Tester, Universal Material Testing Machine

Uses:Suitable for mechanical property testing of materials in aerospace, petrochemical, machinery manufacturing, wire and cable, textile fiber, plastic and rubber, ceramic and food, pharmaceutical packaging, metal materials and other industries. It can automatically calculate test data such as tensile force, breaking force, yield strength, tensile strength, compressive strength, elongation at break, tensile modulus of elasticity, and bending modulus of elasticity according to GB, JIS, ASTM, DIN, ISO and other standards.

Technical Specifications:

Maximum test force: 5–600 kN (model series WDW-5E to WDW-600E)

Test force measurement range: 1%–100% FS, indicated value relative error within ±1% and ±0.5%

Force resolution: 400,000 codes, no gear shifting throughout the whole range; deformation resolution: 4,000,000 codes

Test speed range: 0.01–500 mm/min (depending on model); effective tensile stroke no less than 650 mm

Built-in more than 30 test standards including GB/T228.1-2010, GB/T1040-2008, GB/T528-2009, etc.
