DQM-2型电动隧道防水板焊缝气密性检测仪 (CAS No.None)

Product Name:DQM-2 Electric Tunnel Waterproof Membrane Weld Air Tightness Tester

English Name:DQM-2 Electric Tunnel Waterproof Membrane Weld Air Tightness Tester

Aliases:DQM-2 Weld Air Tightness Tester, Tunnel Waterproof Membrane Weld Air Tightness Tester

Physical Properties:Electric portable testing device powered by AC220V with automatic constant pressure of 0.25MPa. The tester injects air into the weld seam of the waterproof membrane through a No.5 syringe needle and automatically stops inflation at the preset pressure; weld tightness is assessed by pressure retention.

Uses:Developed in accordance with the Technical Code for Waterproofing and Drainage of Railway Tunnels, this instrument is used for air tightness testing of welded seams in tunnel waterproofing membranes. Air is inflated into the weld seam to 0.25MPa and held for 15 minutes; a pressure drop within 10% indicates a qualified weld. If pressure drops too quickly, soapy water can be applied to locate leakage points and re-weld them.

Technical Specifications:

Power supply: AC220V

Working pressure: 0.25MPa, automatic constant pressure (factory-preset, no adjustment required)

Testing method: air inflation into the weld seam via a No.5 syringe needle

Acceptance criteria: pressure drop ≤10% after 15 minutes of holding

Design basis: Technical Code for Waterproofing and Drainage of Railway Tunnels
