多功能交联度测试系统 (CAS No.None)
- 中文别名
- 交联度测试仪；交联度测定系统；交联度分析系统
- 英文名称
- Multi-functional Crosslinking Degree Test System
- 所属类别
- 试剂实验设备
- 物化性质
- 设备外形尺寸为D800×W1500×H2350mm，电源为单相三线制AC220±10%，50±0.5Hz，安装功率约2.0KW。系统由通风柜、萃取装置和检测配件组成：通风柜采用三段式排风结构，钢化玻璃视窗带防落销，上部设通风孔；萃取装置配置500～2000mL大口圆底烧瓶、回流冷凝管（磨口匹配）、加热套或恒温油槽，可加热二甲苯至沸点135～144℃；配真空烘箱（真空度0.87MPa）、120目不锈钢网、精度1/10000g托盘电子分析天平及干燥器。试剂为分析纯二甲苯（A.R.）和抗氧剂。
- 技术参数
- 设备外形尺寸为D800×W1500×H2350mm，电源为单相三线制AC220±10%，50±0.5Hz，安装功率约2.0KW。 配置500mL/1000mL/2000mL大口圆底烧瓶及配套回流冷凝管，磨口尺寸匹配，便于不同样品量的测定。 加热套或恒温油槽热容量可满足二甲苯回流要求，加热沸点135～144℃。 真空烘箱附带真空源，真空度可达0.87MPa，并配套120目不锈钢网和精度1/10000g托盘电子分析天平。 通风柜采用三段式排风结构，钢化玻璃视窗带防落销，上部设通风孔，保证操作安全。
English description（英文原文，共 2338 字符）
Product Name:Multi-functional Crosslinking Degree Test System
English Name:Multi-functional Crosslinking Degree Test System
Aliases:Crosslinking Degree Tester, Crosslinking Degree Measuring System, Crosslinking Degree Analyzer
Physical Properties:Equipment dimensions: D800×W1500×H2350mm; power supply: single-phase three-wire AC220±10%, 50±0.5Hz; installed power: approximately 2.0KW. The system consists of a fume hood, extraction apparatus and testing accessories: the fume hood adopts a three-stage exhaust structure with tempered glass viewing window, anti-fall pin and upper ventilation opening; the extraction apparatus is equipped with 500–2000mL round-bottom flasks, reflux condenser (matched ground joint), heating mantle or constant-temperature oil bath, capable of heating xylene to boiling point 135–144°C; it is also equipped with a vacuum oven (vacuum degree 0.87MPa), 120-mesh stainless steel mesh, 1/10000g precision electronic analytical balance and desiccator. Reagents use analytical grade xylene (A.R.) and antioxidant.
Uses:This test system is used to determine the crosslinking degree of polymer materials (such as polyethylene and cross-linked polyethylene) by solvent extraction method, separating crosslinked and non-crosslinked components under xylene reflux and calculating the crosslinking degree. It is suitable for quality control and product development in the polymer processing industry including wires and cables, pipes and films, and can also be used for process optimization and performance evaluation of polyethylene crosslinking.
Technical Specifications:
Equipment dimensions are D800×W1500×H2350mm; power supply is single-phase three-wire AC220±10%, 50±0.5Hz; installed power is approximately 2.0KW.
Equipped with 500mL/1000mL/2000mL round-bottom flasks and matching reflux condenser with matched ground joint for different sample sizes.
Heating mantle or constant-temperature oil bath has sufficient heat capacity for xylene reflux at boiling point 135–144°C.
Vacuum oven is provided with a vacuum source, vacuum degree up to 0.87MPa, accompanied by 120-mesh stainless steel mesh and 1/10000g precision electronic analytical balance.
Fume hood adopts a three-stage exhaust structure with tempered glass viewing window, anti-fall pin and upper ventilation opening for operational safety.
English Name:Multi-functional Crosslinking Degree Test System
Aliases:Crosslinking Degree Tester, Crosslinking Degree Measuring System, Crosslinking Degree Analyzer
Physical Properties:Equipment dimensions: D800×W1500×H2350mm; power supply: single-phase three-wire AC220±10%, 50±0.5Hz; installed power: approximately 2.0KW. The system consists of a fume hood, extraction apparatus and testing accessories: the fume hood adopts a three-stage exhaust structure with tempered glass viewing window, anti-fall pin and upper ventilation opening; the extraction apparatus is equipped with 500–2000mL round-bottom flasks, reflux condenser (matched ground joint), heating mantle or constant-temperature oil bath, capable of heating xylene to boiling point 135–144°C; it is also equipped with a vacuum oven (vacuum degree 0.87MPa), 120-mesh stainless steel mesh, 1/10000g precision electronic analytical balance and desiccator. Reagents use analytical grade xylene (A.R.) and antioxidant.
Uses:This test system is used to determine the crosslinking degree of polymer materials (such as polyethylene and cross-linked polyethylene) by solvent extraction method, separating crosslinked and non-crosslinked components under xylene reflux and calculating the crosslinking degree. It is suitable for quality control and product development in the polymer processing industry including wires and cables, pipes and films, and can also be used for process optimization and performance evaluation of polyethylene crosslinking.
Technical Specifications:
Equipment dimensions are D800×W1500×H2350mm; power supply is single-phase three-wire AC220±10%, 50±0.5Hz; installed power is approximately 2.0KW.
Equipped with 500mL/1000mL/2000mL round-bottom flasks and matching reflux condenser with matched ground joint for different sample sizes.
Heating mantle or constant-temperature oil bath has sufficient heat capacity for xylene reflux at boiling point 135–144°C.
Vacuum oven is provided with a vacuum source, vacuum degree up to 0.87MPa, accompanied by 120-mesh stainless steel mesh and 1/10000g precision electronic analytical balance.
Fume hood adopts a three-stage exhaust structure with tempered glass viewing window, anti-fall pin and upper ventilation opening for operational safety.
