FD-503 (CAS No.None)
- 物化性质
- FD-503型食品添加剂冻干机为箱体式设计，采用316L奥氏体不锈钢冻干箱，预冻和干燥原位完成。隔板智能控温范围-40℃~+70℃，每层隔板温差小于1℃；冻干仓尺寸630×740×850mm，隔板3层；支持0.2μm过滤的惰性气体回填，配备真空度智能调节和冻干曲线优化控制功能。冷阱全自动一键除霜，采用10寸高清彩色液晶触摸屏，搭载Android操作系统，支持中英文切换，具备数据自动保存、历史复现、三级权限管理及物联网远程监控功能。
- 技术参数
- 隔板控温范围为-40℃~+70℃，每层隔板温度波动小于1℃。 冻干仓尺寸为630×740×850mm，隔板层数为3层，隔板尺寸为359×450×364mm。 抽气速率为2L/s，支持0.2μm过滤的惰性气体回填。 净重177kg，采用箱体式紧凑设计，便于摆放和搬运。 配备10寸高清触摸屏和Android系统，可编辑保存1000条以上工艺配方，每组配方含50个控温区段。
English description（英文原文，共 2036 字符）
Product Name:FD-503 Freeze Dryer for Food Additives
English Name:FD-503 Freeze Dryer for Food Additives
Aliases:FD-503 Lyophilizer, Food Additive Freeze Dryer
Physical Properties:The FD-503 food additive freeze dryer features a chamber-type design with a 316L austenitic stainless steel drying chamber, allowing in-situ pre-freezing and drying. The shelf temperature is intelligently controlled from -40°C to +70°C with a temperature difference of less than 1°C per shelf. The drying chamber dimensions are 630×740×850 mm with 3 shelves. It supports inert gas backfilling with 0.2 μm filtration, vacuum degree intelligent adjustment, and freeze-drying curve optimization control. The cold trap features automatic one-key defrosting. Equipped with a 10-inch high-definition color touchscreen and Android operating system, it supports Chinese/English switching, automatic data storage, history replay, three-level permission management, and IoT remote monitoring.
Uses:This equipment is suitable for hygiene, food, biological, and agricultural fields, especially for freeze-drying enzyme powder in the food additive industry. Enzyme powder processed by freeze-drying can be stored for a long time, is easy to transport, and reduces transportation costs, while well preserving the original active ingredients of the enzymes. The freeze-dried enzyme powder has a crystalline structure and dissolves quickly upon rehydration.
Technical Specifications:
The shelf temperature control range is -40°C to +70°C, with a temperature fluctuation of less than 1°C per shelf.
The drying chamber dimensions are 630×740×850 mm, with 3 shelves and shelf dimensions of 359×450×364 mm.
The pumping speed is 2 L/s, with inert gas backfilling supported via 0.2 μm filtration.
The net weight is 177 kg, and the chamber-type compact design facilitates placement and handling.
Equipped with a 10-inch high-definition touchscreen and Android system, it can edit and store more than 1000 process recipes, each containing 50 temperature control segments.
English Name:FD-503 Freeze Dryer for Food Additives
Aliases:FD-503 Lyophilizer, Food Additive Freeze Dryer
Physical Properties:The FD-503 food additive freeze dryer features a chamber-type design with a 316L austenitic stainless steel drying chamber, allowing in-situ pre-freezing and drying. The shelf temperature is intelligently controlled from -40°C to +70°C with a temperature difference of less than 1°C per shelf. The drying chamber dimensions are 630×740×850 mm with 3 shelves. It supports inert gas backfilling with 0.2 μm filtration, vacuum degree intelligent adjustment, and freeze-drying curve optimization control. The cold trap features automatic one-key defrosting. Equipped with a 10-inch high-definition color touchscreen and Android operating system, it supports Chinese/English switching, automatic data storage, history replay, three-level permission management, and IoT remote monitoring.
Uses:This equipment is suitable for hygiene, food, biological, and agricultural fields, especially for freeze-drying enzyme powder in the food additive industry. Enzyme powder processed by freeze-drying can be stored for a long time, is easy to transport, and reduces transportation costs, while well preserving the original active ingredients of the enzymes. The freeze-dried enzyme powder has a crystalline structure and dissolves quickly upon rehydration.
Technical Specifications:
The shelf temperature control range is -40°C to +70°C, with a temperature fluctuation of less than 1°C per shelf.
The drying chamber dimensions are 630×740×850 mm, with 3 shelves and shelf dimensions of 359×450×364 mm.
The pumping speed is 2 L/s, with inert gas backfilling supported via 0.2 μm filtration.
The net weight is 177 kg, and the chamber-type compact design facilitates placement and handling.
Equipped with a 10-inch high-definition touchscreen and Android system, it can edit and store more than 1000 process recipes, each containing 50 temperature control segments.
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- FD-503的 CAS 号是多少？
- FD-503的 CAS 号是 None。
- FD-503的英文名称是什么？
- FD-503的英文名称为 FD-503 Freeze Dryer for Food Additives。
- FD-503还有哪些别名？
- FD-503又称 FD-503型冷冻干燥机、食品添加剂冻干机。
- FD-503有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条FD-503供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- FD-503的供应商主要分布在哪些地区？
- FD-503的供应商主要分布在 上海市（1 条） 等地。
- FD-503有哪些级别可选？
- 平台上FD-503的供应级别包括 工业级。
- FD-503的报价单位是什么？
- FD-503的报价单位主要有 千克。
- 哪里可以查到FD-503的价格？
- 掌上化工FD-503产品页汇总了各供应商的最新报价与规格，地址：/chemicals/fd-503/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
