FPD-3D全不锈钢型凝固点降低一体化实验装置 (CAS No.None)

Product Name:FPD-3D All Stainless Steel Integrated Freezing Point Depression Experimental Apparatus

English Name:FPD-3D All Stainless Steel Integrated Freezing Point Depression Experimental Apparatus

Aliases:Integrated Freezing Point Depression Experimental Apparatus, FPD-3D Freezing Point Depression Experimental Apparatus

Physical Properties:All stainless steel housing (304 stainless steel) with integrated design, corrosion-resistant and easy to clean; transparent cooling bath for clear observation of crystallization; built-in LED observation light source; magnetic coupling stirrer prevents blockage caused by crystallization and allows convenient disconnection for sample loading and unloading.

Uses:Used in physical chemistry experiments for determining molar mass of solutes by freezing point depression, studying colligative properties of dilute solutions, and also for freezing point determination of organic solvents and observation of crystallization processes.

Technical Specifications:

Temperature measurement range: -50 to 180°C with a resolution of 0.001°C; equipped with a high-precision digital thermometer and recording/analysis software.

Dual temperature display: sample temperature and cooling bath temperature; auxiliary temperature range: -20 to 100°C with a resolution of 0.1°C.

Sensor: miniature PT100 (Φ5×150 mm), response time ≤5 seconds.

Stirring mode: mechanical automatic vertical stirring or rotary stirring optional, with adjustable stirring speed.

Transparent cooling bath design, 304 stainless steel housing, timing and reading lock function included.
