高低温冲击试验箱 (CAS No.None)
- 物化性质
- 设备采用双机复叠式制冷系统，外箱体为优质A3钢板静电喷塑，内箱体为进口SUS304不锈钢；保温层采用硬质聚氨酯泡沫与玻璃纤维复合结构；配备日本原装进口“优易控”温度控制器、PT100铂金电阻测温体及法国泰康/德国比泽尔压缩机；观察窗有效视界为210×275mm或395×395mm。
- 技术参数
- 设备型号包括LRHS-101B-LV、LRHS-150B-LV、LRHS-234B-LV、LRHS-512B-LV、LRHS-753B-LV、LRHS-1000B-LV六种规格，工作室尺寸范围为450×450×500mm至1120×1120×800mm。
English description（英文原文，共 1918 字符）
Product Name:Thermal Shock Test Chamber
English Name:Thermal Shock Test Chamber
Aliases:Temperature Shock Test Chamber, Cold-Hot Impact Test Chamber
Physical Properties:The equipment adopts a two-stage cascade refrigeration system. The outer chamber is made of high-quality A3 steel plate with electrostatic plastic spraying, and the inner chamber is made of imported SUS304 stainless steel. The insulation layer is a composite structure of rigid polyurethane foam and glass fiber. It is equipped with a Japan-imported "U-ECO" temperature controller, PT100 platinum resistance temperature sensor, and French Tecumseh/German Bitzer compressors. The observation window has an effective view of 210×275mm or 395×395mm.
Uses:Applicable to electronics, electrical, automotive, aerospace, and scientific research industries, it is used to test the reliability and durability of products under rapid high-low temperature thermal shock conditions. It can verify the adaptability of materials or products to drastic temperature changes during storage, transportation, and use, and evaluate the structural stability and electrical performance of products. It is widely used in product development, quality inspection, and certification testing.
Technical Specifications:
Models available: LRHS-101B-LV, LRHS-150B-LV, LRHS-234B-LV, LRHS-512B-LV, LRHS-753B-LV, and LRHS-1000B-LV; working chamber dimensions range from 450×450×500mm to 1120×1120×800mm.
Thermal shock temperature range: Type A -40°C to 85°C, Type B -55°C to 85°C, Type C -65°C to 85°C; temperature recovery time ≤5min, basket transfer time ≤15s.
Temperature fluctuation ≤1°C, temperature deviation ±3°C (at no load).
Heating rate: from ambient to 150°C in ≤25min; cooling rate: from ambient to -55°C in ≤45min.
Power supply: AC380V±10%, 50Hz; equipment power: 17~110KW (depending on model and temperature range); operating environment: 5°C~+28°C, ≤85% RH.
English Name:Thermal Shock Test Chamber
Aliases:Temperature Shock Test Chamber, Cold-Hot Impact Test Chamber
Physical Properties:The equipment adopts a two-stage cascade refrigeration system. The outer chamber is made of high-quality A3 steel plate with electrostatic plastic spraying, and the inner chamber is made of imported SUS304 stainless steel. The insulation layer is a composite structure of rigid polyurethane foam and glass fiber. It is equipped with a Japan-imported "U-ECO" temperature controller, PT100 platinum resistance temperature sensor, and French Tecumseh/German Bitzer compressors. The observation window has an effective view of 210×275mm or 395×395mm.
Uses:Applicable to electronics, electrical, automotive, aerospace, and scientific research industries, it is used to test the reliability and durability of products under rapid high-low temperature thermal shock conditions. It can verify the adaptability of materials or products to drastic temperature changes during storage, transportation, and use, and evaluate the structural stability and electrical performance of products. It is widely used in product development, quality inspection, and certification testing.
Technical Specifications:
Models available: LRHS-101B-LV, LRHS-150B-LV, LRHS-234B-LV, LRHS-512B-LV, LRHS-753B-LV, and LRHS-1000B-LV; working chamber dimensions range from 450×450×500mm to 1120×1120×800mm.
Thermal shock temperature range: Type A -40°C to 85°C, Type B -55°C to 85°C, Type C -65°C to 85°C; temperature recovery time ≤5min, basket transfer time ≤15s.
Temperature fluctuation ≤1°C, temperature deviation ±3°C (at no load).
Heating rate: from ambient to 150°C in ≤25min; cooling rate: from ambient to -55°C in ≤45min.
Power supply: AC380V±10%, 50Hz; equipment power: 17~110KW (depending on model and temperature range); operating environment: 5°C~+28°C, ≤85% RH.
