高低温交变湿热试验箱 (CAS No.None)
- 中文别名
- 环境试验箱；高低温湿热交变试验箱
- 英文名称
- High-Low Temperature Alternating Humidity and Heat Test Chamber
- 所属类别
- 试剂实验设备
- 物化性质
- 设备采用BT(H)C平衡调温调湿方式，使用环境温度+5～+35℃。内箱采用SUS304不锈钢板，外箱为冷轧钢板（电脑灰），绝热层为聚氨酯泡沫+玻璃纤维。加热器为镍铬合金电热丝式，加湿采用蒸汽加湿法（或外加湿装置），风机为长轴离心电机多翼式扇叶。制冷系统采用法国进口压缩机，使用R404a/R23环保冷媒，机械压缩单级或二元复叠制冷（风冷）。控制器为TFT真彩液晶触摸屏或按键式，支持中英文菜单和触摸式操控。
- 技术参数
- 满足GB11158、GB10589、GB/T10586、GB/T2423.1/2/22、IEC60068-2-1/2、GJB150.3/4等标准试验方法。
English description（英文原文，共 2477 字符）
Product Name:High-Low Temperature Alternating Humidity and Heat Test Chamber
English Name:High-Low Temperature Alternating Humidity and Heat Test Chamber
Aliases:Environmental Test Chamber, Programmable Temperature and Humidity Chamber
Physical Properties:The chamber adopts BT(H)C balanced temperature and humidity control method, with an operating ambient temperature of +5 to +35°C. The inner box is made of SUS304 stainless steel plate, the outer box is cold-rolled steel plate (computer gray), and the insulation layer is polyurethane foam + glass fiber. The heater is a nickel-chromium alloy electric heating wire; humidification adopts steam humidification (or external humidifier); the fan is a long-axis centrifugal motor with multi-blade impeller. The refrigeration system uses an imported French compressor with eco-friendly refrigerants R404a/R23, and adopts mechanical compression single-stage or cascade refrigeration (air-cooled). The controller is a TFT true-color LCD touch screen or keypad type, supporting Chinese/English menus and touch operation.
Uses:The high-low temperature alternating humidity and heat test chamber, also known as environmental test chamber, can accurately simulate complex natural environments such as low temperature, high temperature, high temperature and high humidity, and low temperature and low humidity. It is suitable for product reliability testing in industries such as plastics, electronics, food, clothing, vehicles, metals, chemicals, and building materials. It complies with multiple national and international standards and is used for product development, quality inspection, and environmental adaptability evaluation.
Technical Specifications:
Complies with test methods of GB11158, GB10589, GB/T10586, GB/T2423.1/2/22, IEC60068-2-1/2, GJB150.3/4, etc.
Temperature range: -20°C to +150°C / -40°C to +150°C / -70°C to +150°C (depending on model); humidity range: 20 to 98% RH.
Temperature fluctuation: ±0.5°C, temperature deviation: ±2°C; humidity deviation: ±3.0% RH (>75% RH), ±5.0% RH (≤75% RH).
Heating time: -20 to +150°C ≤30 min, -40 to +150°C ≤40 min, -70 to +150°C ≤60 min; cooling time: +20 to -20°C ≤40 min, +20 to -40°C ≤60 min, +20 to -70°C ≤80 min.
The controller adopts TFT true-color LCD touch screen or keypad type, supports program running and fixed value running, with capacity of 120 program groups and 100 segments per group; temperature and humidity control mode is BT(H)C balanced type.
English Name:High-Low Temperature Alternating Humidity and Heat Test Chamber
Aliases:Environmental Test Chamber, Programmable Temperature and Humidity Chamber
Physical Properties:The chamber adopts BT(H)C balanced temperature and humidity control method, with an operating ambient temperature of +5 to +35°C. The inner box is made of SUS304 stainless steel plate, the outer box is cold-rolled steel plate (computer gray), and the insulation layer is polyurethane foam + glass fiber. The heater is a nickel-chromium alloy electric heating wire; humidification adopts steam humidification (or external humidifier); the fan is a long-axis centrifugal motor with multi-blade impeller. The refrigeration system uses an imported French compressor with eco-friendly refrigerants R404a/R23, and adopts mechanical compression single-stage or cascade refrigeration (air-cooled). The controller is a TFT true-color LCD touch screen or keypad type, supporting Chinese/English menus and touch operation.
Uses:The high-low temperature alternating humidity and heat test chamber, also known as environmental test chamber, can accurately simulate complex natural environments such as low temperature, high temperature, high temperature and high humidity, and low temperature and low humidity. It is suitable for product reliability testing in industries such as plastics, electronics, food, clothing, vehicles, metals, chemicals, and building materials. It complies with multiple national and international standards and is used for product development, quality inspection, and environmental adaptability evaluation.
Technical Specifications:
Complies with test methods of GB11158, GB10589, GB/T10586, GB/T2423.1/2/22, IEC60068-2-1/2, GJB150.3/4, etc.
Temperature range: -20°C to +150°C / -40°C to +150°C / -70°C to +150°C (depending on model); humidity range: 20 to 98% RH.
Temperature fluctuation: ±0.5°C, temperature deviation: ±2°C; humidity deviation: ±3.0% RH (>75% RH), ±5.0% RH (≤75% RH).
Heating time: -20 to +150°C ≤30 min, -40 to +150°C ≤40 min, -70 to +150°C ≤60 min; cooling time: +20 to -20°C ≤40 min, +20 to -40°C ≤60 min, +20 to -70°C ≤80 min.
The controller adopts TFT true-color LCD touch screen or keypad type, supports program running and fixed value running, with capacity of 120 program groups and 100 segments per group; temperature and humidity control mode is BT(H)C balanced type.
