高压气体等温吸附仪 (CAS No.None)
- 技术参数
- 吸附温度范围20～200℃，恒温油浴控温精度±0.1℃（显示）/±0.01℃（软件控制），电加热可达400℃用于样品预处理 样品腔最高压力大于500个大气压（约50MPa），配备40MPa高压和4MPa中压压力传感器，压力精度优于0.1%全量程 样品池可直接放置60g样品或岩心样品，也可支持1～10g少量样品检测，分辨率10μg 系统真空度0.1Pa，配置自动压力控制系统和4路高压电磁阀，实现全自动数据采集与追溯 配置进口高压气体增压泵，可将待测气体增压至40MPa；多气体入口适应氮气、氦气、甲烷、二氧化碳、乙烷等气体
English description（英文原文，共 1647 字符）
Product Name:High Pressure Gas Isothermal Adsorption Analyzer
English Name:High Pressure Gas Isothermal Adsorption Analyzer
Aliases:High Pressure Gas Sorption Analyzer, Gravimetric High Pressure Isothermal Adsorption Analyzer
Uses:Used for isothermal adsorption characterization of pure gases or mixtures of methane, carbon dioxide, and high-molecular-weight hydrocarbon gases, supporting single-component and multi-component experiments. It enables adsorption measurement on rock samples under simulated geological conditions. Based on the gravimetric method, it directly measures the adsorbed amount of the sample, and can be used for high-pressure adsorption isotherm studies and binary gas competitive adsorption analysis.
Technical Specifications:
Adsorption temperature range: 20–200 °C; temperature control accuracy of constant-temperature oil bath: ±0.1 °C (display) / ±0.01 °C (software control); electric heating up to 400 °C for sample pretreatment
Maximum sample cell pressure: greater than 500 atm (approx. 50 MPa); equipped with high-pressure (40 MPa) and medium-pressure (4 MPa) sensors with accuracy better than 0.1% of full scale
Sample cell capacity: directly holds 60 g of sample or core samples, also supports 1–10 g small samples with a resolution of 10 μg
System vacuum degree: 0.1 Pa; fully automatic pressure control system with 4 high-pressure solenoid valves for automatic data acquisition and traceability
Equipped with an imported high-pressure gas booster pump capable of pressurizing test gases to 40 MPa; multiple gas inlets compatible with nitrogen, helium, methane, carbon dioxide, ethane, and other gases
English Name:High Pressure Gas Isothermal Adsorption Analyzer
Aliases:High Pressure Gas Sorption Analyzer, Gravimetric High Pressure Isothermal Adsorption Analyzer
Uses:Used for isothermal adsorption characterization of pure gases or mixtures of methane, carbon dioxide, and high-molecular-weight hydrocarbon gases, supporting single-component and multi-component experiments. It enables adsorption measurement on rock samples under simulated geological conditions. Based on the gravimetric method, it directly measures the adsorbed amount of the sample, and can be used for high-pressure adsorption isotherm studies and binary gas competitive adsorption analysis.
Technical Specifications:
Adsorption temperature range: 20–200 °C; temperature control accuracy of constant-temperature oil bath: ±0.1 °C (display) / ±0.01 °C (software control); electric heating up to 400 °C for sample pretreatment
Maximum sample cell pressure: greater than 500 atm (approx. 50 MPa); equipped with high-pressure (40 MPa) and medium-pressure (4 MPa) sensors with accuracy better than 0.1% of full scale
Sample cell capacity: directly holds 60 g of sample or core samples, also supports 1–10 g small samples with a resolution of 10 μg
System vacuum degree: 0.1 Pa; fully automatic pressure control system with 4 high-pressure solenoid valves for automatic data acquisition and traceability
Equipped with an imported high-pressure gas booster pump capable of pressurizing test gases to 40 MPa; multiple gas inlets compatible with nitrogen, helium, methane, carbon dioxide, ethane, and other gases
