工业烤箱热风循环烘箱鼓风干燥箱 (CAS No.None)

Product Name:Hot Air Circulating Oven

English Name:Hot Air Circulating Oven

Aliases:Industrial Oven, Forced Air Drying Oven

Physical Properties:This equipment is a forced hot air circulating drying oven. The inner chamber is made of high-quality SUS304 mirror stainless steel plate, the outer shell is made of high-strength steel plate with high-temperature resistant powder coating, and the insulation layer is high-density rock wool with heat insulation device. It is equipped with a double-layer glass observation window and adopts microcomputer PID control, featuring uniform temperature distribution, high temperature control accuracy and simple operation.

Uses:It is suitable for industrial and mining enterprises, scientific research institutions, medical and health, electronics, chemical and other industries, for drying, baking, heat treatment, curing, sterilization and aging tests of items.

Technical Specifications:

Temperature range: room temperature +20°C to 200°C/300°C; control accuracy: ±0.5°C; resolution: 0.1°C; temperature fluctuation: ±0.5°C; temperature distribution error: ≤±1.5%.

Inner chamber size: 75×60×50 cm (customizable); inner chamber material: SUS304 stainless steel, thickness 1.2 mm; outer shell material: high-strength steel plate with high-temperature resistant powder coating, thickness 1.5 mm.

Heater: nickel-chromium alloy electric heater, power 3 kW; total power: 4 kW; circulation motor: TECO (Taiwan) 0.5 HP.

Control system: microcomputer PID control with PID self-tuning function; controller: Taiwan TB-900; temperature sensor: industrial platinum resistance (PT100).

Safety protection: independent over-temperature protection device (Korea Samwon over-temperature protector); power switch: Taiwan Shihlin leakage protection switch; contactor and relay: Taiwan TAIAN.
