GR-10 双层玻璃反应釜 (CAS No.None)
- 物化性质
- 主体采用高硼硅玻璃3.3，固定架及连接件为不锈钢304，具有优良物理化学性能；适用温度范围-80~200℃；可在常压及真空条件下工作，静止状态下真空度可达0.095MPa以下；夹层可通入冷冻液、水或高温液对物料进行升温和冷却。
- 技术参数
- 反应釜釜内有效容积10L，夹套容积3L，夹套换热面积0.22m²，冷凝器换热面积0.17m²。 反应釜釜体耐受温度-80~200℃，操作压力-0.1MPa~常压。 搅拌系统采用变频调速，转速0~500rpm，电机功率90W。 釜盖开口共6个，包括搅拌口、传感器口、冷凝器连接口、液体加料口、恒压漏斗接口和固体加料口。 放料阀为无积液侧放料阀，距地面有效尺寸约380mm；整机电源220V，50/60Hz；外形尺寸720L×520W×1780H mm。
English description（英文原文，共 1869 字符）
Product Name:GR-10 Double-layer Glass Reactor
English Name:GR-10 Double-layer Glass Reactor
Aliases:10L Double-layer Glass Reactor
Physical Properties:The main body is made of borosilicate glass 3.3, and the frame and connectors are made of stainless steel 304, offering excellent physical and chemical properties. It can be used over a temperature range of -80 to 200°C, and works under atmospheric pressure or vacuum with a vacuum degree up to below 0.095 MPa under static conditions. The jacket can be filled with cooling liquid, water or high-temperature liquid for heating and cooling the materials.
Uses:The inner layer of the double-layer glass reactor holds reaction materials, and the reactor can be evacuated and stirred at adjustable speeds. The jacket can be filled with cooling liquid, water or high-temperature liquid to heat or cool the materials. It is used in experiments, pilot tests and production in chemistry, fine chemicals, biopharmaceuticals and new material synthesis. It can be combined with water-circulating vacuum pumps, diaphragm vacuum pumps, low-temperature circulating pumps, recirculating coolers, thermostatic circulators, etc. to form a complete system.
Technical Specifications:
Effective volume of reactor: 10L; jacket volume: 3L; jacket heat exchange area: 0.22m²; condenser heat exchange area: 0.17m².
Temperature resistance of reactor body: -80 to 200°C; operating pressure: -0.1MPa to atmospheric pressure.
Stirring system with frequency conversion speed regulation, speed 0-500rpm, motor power 90W.
Reactor lid has 6 openings: stirring port, sensor port, condenser connection port, liquid feeding port, constant-pressure funnel port and solid feeding port.
Discharge valve is a side valve without dead volume, effective distance from ground approx. 380mm; power supply: 220V, 50/60Hz; dimensions: 720L×520W×1780H mm.
English Name:GR-10 Double-layer Glass Reactor
Aliases:10L Double-layer Glass Reactor
Physical Properties:The main body is made of borosilicate glass 3.3, and the frame and connectors are made of stainless steel 304, offering excellent physical and chemical properties. It can be used over a temperature range of -80 to 200°C, and works under atmospheric pressure or vacuum with a vacuum degree up to below 0.095 MPa under static conditions. The jacket can be filled with cooling liquid, water or high-temperature liquid for heating and cooling the materials.
Uses:The inner layer of the double-layer glass reactor holds reaction materials, and the reactor can be evacuated and stirred at adjustable speeds. The jacket can be filled with cooling liquid, water or high-temperature liquid to heat or cool the materials. It is used in experiments, pilot tests and production in chemistry, fine chemicals, biopharmaceuticals and new material synthesis. It can be combined with water-circulating vacuum pumps, diaphragm vacuum pumps, low-temperature circulating pumps, recirculating coolers, thermostatic circulators, etc. to form a complete system.
Technical Specifications:
Effective volume of reactor: 10L; jacket volume: 3L; jacket heat exchange area: 0.22m²; condenser heat exchange area: 0.17m².
Temperature resistance of reactor body: -80 to 200°C; operating pressure: -0.1MPa to atmospheric pressure.
Stirring system with frequency conversion speed regulation, speed 0-500rpm, motor power 90W.
Reactor lid has 6 openings: stirring port, sensor port, condenser connection port, liquid feeding port, constant-pressure funnel port and solid feeding port.
Discharge valve is a side valve without dead volume, effective distance from ground approx. 380mm; power supply: 220V, 50/60Hz; dimensions: 720L×520W×1780H mm.
