GR-20L变频调速双层玻璃反应釜 (CAS No.None)
- 中文别名
- 20L双层玻璃反应釜；变频调速双层玻璃反应釜
- 英文名称
- GR-20L Variable Frequency Speed-Regulating Double-Layer Glass Reactor
- 所属类别
- 试剂实验设备
- 物化性质
- 采用高硼硅3.3玻璃材质，具有优良的物理和化学性能；可在常压及真空条件下工作，静止状态下真空度可达0.095MPa以下；配备数字显示变频恒速搅拌系统，运行平稳；PTFE搅拌桨及防腐放料阀无死腔设计，夹套溶液可排净不积液。
- 技术参数
- 反应釜釜内有效容积20L，夹套容积6L，夹套换热面积0.32m²，冷凝器换热面积0.3m²。 釜体耐受温度-80~200℃，操作压力为真空或常压。 搅拌系统为变频调速，转速50~500rpm，电机功率90W，数字显示搅拌速度。 反应釜主体为高硼硅3.3玻璃，固定架及连接件为不锈钢304，密封件为聚四氟乙烯；釜盖开口6个，放料阀为无积液侧放料阀。 整机电源220V/50Hz，外形尺寸约520mm×520mm×2030mm，放料阀距地面约370mm。
English description（英文原文，共 2021 字符）
Product Name:GR-20L Variable Frequency Speed-Regulating Double-Layer Glass Reactor
English Name:GR-20L Variable Frequency Speed-Regulating Double-Layer Glass Reactor
Aliases:20L Double-Layer Glass Reactor, Variable Frequency Speed-Regulating Double-Layer Glass Reactor
Physical Properties:Made of borosilicate glass 3.3 with excellent physical and chemical properties; can operate under atmospheric pressure and vacuum, with static vacuum up to or below 0.095 MPa; equipped with a digital display variable-frequency constant-speed stirring system for stable operation; PTFE stirring paddle and corrosion-resistant discharge valve with no dead volume; jacket solution can be completely drained without accumulation.
Uses:The inner vessel holds reaction materials and supports vacuum operation and adjustable stirring; the jacket can be filled with cooling liquid, water or high-temperature liquid for heating and cooling. It is used in experiments, pilot tests and production in chemistry, fine chemicals, biopharmaceuticals and new material synthesis. It can be combined with circulating water vacuum pumps, diaphragm vacuum pumps, low-temperature circulating pumps, recirculating coolers, thermostatic circulators, low-temperature coolant circulation pumps and sealed refrigeration/heating circulation units to form a system.
Technical Specifications:
Effective volume: 20 L; jacket volume: 6 L; jacket heat exchange area: 0.32 m²; condenser heat exchange area: 0.3 m².
Temperature resistance of the reactor body: -80 to 200°C; operating pressure: vacuum or atmospheric pressure.
Stirring system: variable frequency speed control, speed 50-500 rpm, motor power 90 W, digital speed display.
Main materials: borosilicate glass 3.3 for reactor body, stainless steel 304 for frame and connectors, PTFE for seals; lid has 6 ports; discharge valve is a no-liquid-retention side valve.
Power supply: 220V/50Hz; overall dimensions: approx. 520 mm × 520 mm × 2030 mm; discharge valve height from ground: approx. 370 mm.
English Name:GR-20L Variable Frequency Speed-Regulating Double-Layer Glass Reactor
Aliases:20L Double-Layer Glass Reactor, Variable Frequency Speed-Regulating Double-Layer Glass Reactor
Physical Properties:Made of borosilicate glass 3.3 with excellent physical and chemical properties; can operate under atmospheric pressure and vacuum, with static vacuum up to or below 0.095 MPa; equipped with a digital display variable-frequency constant-speed stirring system for stable operation; PTFE stirring paddle and corrosion-resistant discharge valve with no dead volume; jacket solution can be completely drained without accumulation.
Uses:The inner vessel holds reaction materials and supports vacuum operation and adjustable stirring; the jacket can be filled with cooling liquid, water or high-temperature liquid for heating and cooling. It is used in experiments, pilot tests and production in chemistry, fine chemicals, biopharmaceuticals and new material synthesis. It can be combined with circulating water vacuum pumps, diaphragm vacuum pumps, low-temperature circulating pumps, recirculating coolers, thermostatic circulators, low-temperature coolant circulation pumps and sealed refrigeration/heating circulation units to form a system.
Technical Specifications:
Effective volume: 20 L; jacket volume: 6 L; jacket heat exchange area: 0.32 m²; condenser heat exchange area: 0.3 m².
Temperature resistance of the reactor body: -80 to 200°C; operating pressure: vacuum or atmospheric pressure.
Stirring system: variable frequency speed control, speed 50-500 rpm, motor power 90 W, digital speed display.
Main materials: borosilicate glass 3.3 for reactor body, stainless steel 304 for frame and connectors, PTFE for seals; lid has 6 ports; discharge valve is a no-liquid-retention side valve.
Power supply: 220V/50Hz; overall dimensions: approx. 520 mm × 520 mm × 2030 mm; discharge valve height from ground: approx. 370 mm.
