固定床催化剂评价反应装置 (CAS No.None)
- 中文别名
- 固定床反应器；催化剂评价装置；固定床催化反应评价装置
- 英文名称
- Fixed-Bed Catalyst Evaluation Reaction Apparatus
- 所属类别
- 试剂实验设备
- 物化性质
- 该装置为固定床催化反应评价系统，主要由反应炉、汽化器、流量计、液体泵及管路系统组成。反应炉采用电炉丝、硅碳棒或硅钼棒作为加热元件，最高使用温度可达1000 °C，并采用双热电偶分别进行温度控制与显示；配备温度报警和可燃气体报警系统，安全可靠。反应炉上端空心区域内设有M型加热器，保证汽化器后管道及反应管接头无冷点；气路在面板上直观可见，可脱离计算机手动操作；主体采用铝合金框架，各模块支架固定，便于拆卸和位置变更。
- 技术参数
- 管道采用英制1/16、1/8、1/4、1/2英寸及公制3 mm、6 mm、8 mm、10 mm等规格。 反应温度范围为RT~1000 °C，温度控制精度<±1 °C，温度稳定性<±1 °C。
English description（英文原文，共 2258 字符）
Product Name:Fixed-Bed Catalyst Evaluation Reaction Apparatus
English Name:Fixed-Bed Catalyst Evaluation Reaction Apparatus
Aliases:Fixed-Bed Reactor, Catalyst Evaluation Unit, Fixed-Bed Catalytic Reaction Evaluation Apparatus
Physical Properties:This apparatus is a fixed-bed catalytic reaction evaluation system, mainly composed of a reactor furnace, vaporizer, flow meters, liquid pump, and piping system. The reactor furnace uses electric heating wire, silicon carbide rods, or silicon-molybdenum rods as heating elements, with a maximum operating temperature of 1000 °C; dual thermocouples are used for independent temperature control and display. It is equipped with temperature and combustible gas alarm systems for safe and reliable operation. An M-type heater is arranged in the hollow region at the top of the furnace to eliminate cold spots in the downstream piping and reactor tube joints. The gas circuit is clearly visible on the panel, allowing manual operation without a computer. The main frame is made of aluminum alloy, and all modules are mounted on supports for easy disassembly and repositioning.
Uses:This apparatus is mainly used for catalyst performance evaluation and structure-activity relationship research in laboratories of research institutes. It is widely applicable in petroleum refining, petrochemical, coal chemical, natural gas chemical, fine chemical, environmental protection, and clean energy fields. It is suitable for various fixed-bed catalytic reaction processes such as high-temperature dehydrogenation, high-temperature cracking, denitration, hydrotreating and reforming, heavy oil hydrogenation, VOCs catalytic oxidation, Fischer-Tropsch synthesis, and alkane isomerization.
Technical Specifications:
Piping: imperial 1/16, 1/8, 1/4, 1/2 inch and metric 3 mm, 6 mm, 8 mm, 10 mm, etc.
Reaction temperature range: RT to 1000 °C, temperature control accuracy <±1 °C, temperature stability <±1 °C.
Reaction pressure: atmospheric pressure for quartz reactor tube, 0–20 MPa for stainless steel reactor tube.
Reactor tube: inner diameter 8–50 mm, length 100–1200 mm, catalyst loading <500 ml.
Liquid plunger pump: flow rate 0.001–4.999 ml/min (or 0.01–9.99 ml/min), maximum pressure 40 MPa, flow accuracy ±3%.
English Name:Fixed-Bed Catalyst Evaluation Reaction Apparatus
Aliases:Fixed-Bed Reactor, Catalyst Evaluation Unit, Fixed-Bed Catalytic Reaction Evaluation Apparatus
Physical Properties:This apparatus is a fixed-bed catalytic reaction evaluation system, mainly composed of a reactor furnace, vaporizer, flow meters, liquid pump, and piping system. The reactor furnace uses electric heating wire, silicon carbide rods, or silicon-molybdenum rods as heating elements, with a maximum operating temperature of 1000 °C; dual thermocouples are used for independent temperature control and display. It is equipped with temperature and combustible gas alarm systems for safe and reliable operation. An M-type heater is arranged in the hollow region at the top of the furnace to eliminate cold spots in the downstream piping and reactor tube joints. The gas circuit is clearly visible on the panel, allowing manual operation without a computer. The main frame is made of aluminum alloy, and all modules are mounted on supports for easy disassembly and repositioning.
Uses:This apparatus is mainly used for catalyst performance evaluation and structure-activity relationship research in laboratories of research institutes. It is widely applicable in petroleum refining, petrochemical, coal chemical, natural gas chemical, fine chemical, environmental protection, and clean energy fields. It is suitable for various fixed-bed catalytic reaction processes such as high-temperature dehydrogenation, high-temperature cracking, denitration, hydrotreating and reforming, heavy oil hydrogenation, VOCs catalytic oxidation, Fischer-Tropsch synthesis, and alkane isomerization.
Technical Specifications:
Piping: imperial 1/16, 1/8, 1/4, 1/2 inch and metric 3 mm, 6 mm, 8 mm, 10 mm, etc.
Reaction temperature range: RT to 1000 °C, temperature control accuracy <±1 °C, temperature stability <±1 °C.
Reaction pressure: atmospheric pressure for quartz reactor tube, 0–20 MPa for stainless steel reactor tube.
Reactor tube: inner diameter 8–50 mm, length 100–1200 mm, catalyst loading <500 ml.
Liquid plunger pump: flow rate 0.001–4.999 ml/min (or 0.01–9.99 ml/min), maximum pressure 40 MPa, flow accuracy ±3%.
