轨道板静载试验机 (CAS No.None)
- 物化性质
- 设备由加载机架、移动小车、移动滑轨载架、油源系统、测控系统组成。采用高刚性、高稳定性负荷机架，刚度大、强度高、变形小；油缸上置，试验区域1500×1200mm，方便试件装卸；配置高精度负荷力传感器和双控双向液压油缸，可实现快速试验与快速返回。测控系统具备自动控制、数据采集、处理、分析、存储及显示功能，控制模式智能设置，切换无冲击，加载卸载平稳；具备多重保护功能，包括油缸限位保护、液压过载溢流保护、试验力过载保护、过流过压保护等。
English description（英文原文，共 2112 字符）
Product Name:Track Slab Static Load Testing Machine
English Name:Track Slab Static Load Testing Machine
Aliases:Static Load Testing Machine for Track Slab, Ballastless Track Slab Static Load Test Machine
Physical Properties:The equipment consists of a loading frame, a mobile trolley, a mobile slide rail carrier, an oil source system, and a measurement and control system. It adopts a high-rigidity, high-stability loading frame with large stiffness, high strength, and small deformation. The cylinder is mounted on top, providing a spacious test area of 1500×1200 mm for easy specimen loading. It is equipped with a high-precision load cell and a dual-control bidirectional hydraulic cylinder, enabling fast testing and rapid return. The measurement and control system supports automatic control, data acquisition, processing, analysis, storage, and display. The control modes are intelligently set with smooth switching without impact, ensuring stable loading and unloading. Multiple protections are provided, including cylinder limit protection, hydraulic overload overflow protection, test force overload protection, overcurrent and overvoltage protection, etc.
Uses:It is used to perform static load failure tests on the bottom and middle sections of track slabs (e.g., 6450×2550×200 mm, 8630 kg C60/C55/C40 concrete track slabs), including loading, holding, and cracking tests, to determine the actual bearing capacity of the track slabs. It is applicable to structural tests of CRTS-III, CRTS-II, TBS ballastless track slabs, double-block ballastless track, high-speed railway tracks, etc. It can also be used to inspect bending moment, cracking moment, cracking load value, ultimate bearing capacity, failure load value, and to measure load-deflection curves, crack distribution, and crack width.
Technical Specifications:
Test force: 1000 kN (600 kN optional)
Test force measurement range: 1%~100%FS, no shifting throughout the whole range
Test force accuracy: ≤±1%
Loading rate: 0~40 kN/s, arbitrary setting
Piston stroke: 0~200 mm; static load test height: 0~900 mm; test area: 1500×1200 mm
English Name:Track Slab Static Load Testing Machine
Aliases:Static Load Testing Machine for Track Slab, Ballastless Track Slab Static Load Test Machine
Physical Properties:The equipment consists of a loading frame, a mobile trolley, a mobile slide rail carrier, an oil source system, and a measurement and control system. It adopts a high-rigidity, high-stability loading frame with large stiffness, high strength, and small deformation. The cylinder is mounted on top, providing a spacious test area of 1500×1200 mm for easy specimen loading. It is equipped with a high-precision load cell and a dual-control bidirectional hydraulic cylinder, enabling fast testing and rapid return. The measurement and control system supports automatic control, data acquisition, processing, analysis, storage, and display. The control modes are intelligently set with smooth switching without impact, ensuring stable loading and unloading. Multiple protections are provided, including cylinder limit protection, hydraulic overload overflow protection, test force overload protection, overcurrent and overvoltage protection, etc.
Uses:It is used to perform static load failure tests on the bottom and middle sections of track slabs (e.g., 6450×2550×200 mm, 8630 kg C60/C55/C40 concrete track slabs), including loading, holding, and cracking tests, to determine the actual bearing capacity of the track slabs. It is applicable to structural tests of CRTS-III, CRTS-II, TBS ballastless track slabs, double-block ballastless track, high-speed railway tracks, etc. It can also be used to inspect bending moment, cracking moment, cracking load value, ultimate bearing capacity, failure load value, and to measure load-deflection curves, crack distribution, and crack width.
Technical Specifications:
Test force: 1000 kN (600 kN optional)
Test force measurement range: 1%~100%FS, no shifting throughout the whole range
Test force accuracy: ≤±1%
Loading rate: 0~40 kN/s, arbitrary setting
Piston stroke: 0~200 mm; static load test height: 0~900 mm; test area: 1500×1200 mm
