恒温金属浴 (CAS No.None)

Product Name:Constant Temperature Metal Bath

English Name:Constant Temperature Metal Bath

Aliases:Dry Bath Heater, Block Heater

Physical Properties:Compact and lightweight with palm-sized dimensions for easy portability; heating accuracy ±0.2–0.3 °C, temperature stability ±0.1–0.2 °C. The modular heat-conducting block design allows a single unit to accommodate various tube types including 0.2 mL 96-well PCR plates and 1.5–2.0 mL EP tubes; the standard accessory is a silicone-rubber/metal composite heat-conducting block for faster heating and cooling rates. Equipped with a lightweight, transparent insulating cover that provides excellent thermal insulation and low energy consumption.

Uses:Suitable for crowded laboratories and space-constrained applications, such as clean benches and clean workshops that require a clean and sterile environment. It can also be used in third-party diagnostic laboratories and hospital testing laboratories for temperature-controlled operations including sample incubation, enzymatic reaction incubation, and PCR reactions.

Technical Specifications:

Model: 2016C refrigerated type; temperature setting range: -10 °C to 100 °C; timer range: 1 minute to 24 hours.

Heating accuracy: ±0.2–0.3 °C; temperature stability: ±0.1–0.2 °C.

Heating rate: 60 °C rise from room temperature in less than 3 min unloaded, approximately 10 min with 4 modules loaded; cooling rate: 20 °C drop from room temperature in less than 3 min unloaded, approximately 11 min with 4 modules loaded.

Standard modules include a low insulating cover (90111), 0.2 mL × 24-well module (90101), 0.5 mL × 12-well module (90102), 1.5 mL × 6-well module (90103), and 2.0 mL × 6-well module (90105); optional modules include 15 mL × 6-well, 50 mL × 3-well, 0.2 mL × 96-well, 1.5 mL × 24-well, and a high insulating cover.

Power input: DC 12 V/5 A; operating ambient temperature: 10 °C to 35 °C, relative humidity < 80%; dimensions: 150 × 150 × 25 mm (excluding feet), weight: 650 g.
