化验室光谱仪配套全自动氩气净化机 (CAS No.None)

Product Name:Fully Automatic Argon Purifier for Laboratory Spectrometer

English Name:Fully Automatic Argon Purifier for Laboratory Spectrometer

Aliases:Argon Gas Purifier, Automatic Argon Purification Unit, Spectrometer Argon Gas Purification System, Model CZA-4C Argon Purifier

Physical Properties:This argon purification system uses argon as the working medium. The outlet gas purity reaches 99.9999%, with dew point ≤-76°C (water content ≤1ppm), O2 ≤0.1ppm, N2 ≤0.5ppm, CO+CO2 ≤0.1ppm, and S/P oxides ≤0.1ppm.

Uses:This purifier uses a catalyst to promote the reaction of trace oxygen in argon with carbon to form carbon dioxide, removing oxygen impurities, then molecular sieves adsorb H2O, CO2 and other impurities, and finally an alloy adsorbent removes N2 and other inert impurities to produce high-purity argon. It is compatible with direct-reading spectrometers, fluorescence spectrometers, glow discharge spectrometers, etc., improving the reliability and stability of analytical data while significantly reducing high-purity argon costs. It can also serve as a protective atmosphere for high-purity materials such as monocrystalline silicon, polycrystalline silicon, and high-purity metals.

Technical Specifications:

Outlet argon purity: 99.9999%; particle count (≥0.3 μm): 3-5 particles/L.

Working pressure: 0.4-0.8 MPa; processing capacity: 4 Nm³/h.

Equipment dimensions: 600 mm × 700 mm × 1600 mm; weight: 150 kg.

Dual-tower design with one tower working while the other regenerating, enabling continuous gas supply; regeneration requires no hydrogen, ensuring high safety; the system uses zero-leakage bellows valves for stable and reliable operation.
