混凝土标准养护室设备 (CAS No.None)

Product Name:Concrete Standard Curing Room Equipment

English Name:Concrete Standard Curing Room Equipment

Aliases:Standard curing room equipment, Concrete curing chamber equipment, FHBS series curing room equipment

Physical Properties:The equipment is composed of a control unit, heating/cooling circulation devices, an air conditioner outdoor unit, ventilation ducts, and an industrial humidifier (high-pressure spray pump). It adopts a synchronized temperature-humidity control method. Hot air is blown in winter to raise the indoor temperature to the required level, while cold air is blown in summer to lower it. Humidity is automatically controlled according to the instrument setpoint, achieving a fully automatic constant temperature and humidity environment.

Uses:It is applicable for temperature and humidity control of standard curing rooms in cement plants, cement product plants, commercial concrete mixing stations, construction engineering, traffic engineering, highway construction units, scientific research institutions, and quality inspection stations. It provides a constant temperature and humidity environment for concrete specimens to ensure concrete curing quality.

Technical Specifications:

Measurement and control range: temperature 0-50°C, humidity 0-99%RH.

Temperature control sensitivity: ±0.5°C; humidity control sensitivity: ±2%RH.

Temperature measurement accuracy: ±0.5°C; humidity measurement accuracy: +5% to -3%RH.

Cooling power: 4000W; heating power: 12KW; working power consumption: 14KW; power supply: AC380V (three-phase four-wire), 50Hz.

Working volume of curing room: ≤100 m³ (larger curing rooms can be customized).
