IPX9K高压喷淋试验箱 (CAS No.None)
- 物化性质
- 设备主体采用304不锈钢制造，内壳厚度1.2mm，外壳厚度1.5mm，水箱容积200L；喷水压力8000~10000kPa，喷水温度RT+10℃~90℃可调；试样台转速1~10r/min可调，承重≤35kg；控制系统为PLC加触摸屏人机界面。
- 技术参数
- 试验时间30s（4个位置共120s），喷水环角度0°/30°/60°/90°可调。 喷水孔数4个，可选择单独或选择型；喷水距离100mm~200mm手动调节。 喷水压力8000~10000kPa（手动可调），电磁流量计流量14~16L/min。 试样台转速1~10r/min可调，可正反转，承重≤35kg。 箱体材质304不锈钢，内壳1.2mm，外壳1.5mm，水箱容积200L，工作电压380V，额定功率10kW。
English description（英文原文，共 1373 字符）
Product Name:IPX9K High Pressure Spray Test Chamber
English Name:IPX9K High Pressure Spray Test Chamber
Aliases:High Pressure Spray Test Chamber, IPX9K Water Spray Test Chamber
Physical Properties:The equipment body is made of 304 stainless steel, with inner shell thickness 1.2mm, outer shell thickness 1.5mm, and water tank capacity 200L. Spray water pressure is 8000~10000kPa, spray water temperature is adjustable from RT+10°C to 90°C. Sample table speed is adjustable from 1 to 10r/min, load capacity ≤35kg. The control system adopts PLC with touch screen HMI.
Uses:It is used for waterproof rating testing of enclosures such as electrical/electronic products, lamps, and automotive parts. It simulates high-pressure water spray environments to verify compliance with IEC60529, GB4208, DIN40050-9, and ISO20653 standards.
Technical Specifications:
Test duration 30s (120s total for 4 positions); spray ring angles 0°, 30°, 60°, 90° adjustable.
4 spray nozzles, individually selectable; spray distance 100mm~200mm manually adjustable.
Spray pressure 8000~10000kPa (manually adjustable); electromagnetic flowmeter flow 14~16L/min.
Sample table speed 1~10r/min adjustable, forward and reverse rotation, load capacity ≤35kg.
Chamber material: 304 stainless steel, inner shell 1.2mm, outer shell 1.5mm, water tank volume 200L, power supply 380V, rated power 10kW.
English Name:IPX9K High Pressure Spray Test Chamber
Aliases:High Pressure Spray Test Chamber, IPX9K Water Spray Test Chamber
Physical Properties:The equipment body is made of 304 stainless steel, with inner shell thickness 1.2mm, outer shell thickness 1.5mm, and water tank capacity 200L. Spray water pressure is 8000~10000kPa, spray water temperature is adjustable from RT+10°C to 90°C. Sample table speed is adjustable from 1 to 10r/min, load capacity ≤35kg. The control system adopts PLC with touch screen HMI.
Uses:It is used for waterproof rating testing of enclosures such as electrical/electronic products, lamps, and automotive parts. It simulates high-pressure water spray environments to verify compliance with IEC60529, GB4208, DIN40050-9, and ISO20653 standards.
Technical Specifications:
Test duration 30s (120s total for 4 positions); spray ring angles 0°, 30°, 60°, 90° adjustable.
4 spray nozzles, individually selectable; spray distance 100mm~200mm manually adjustable.
Spray pressure 8000~10000kPa (manually adjustable); electromagnetic flowmeter flow 14~16L/min.
Sample table speed 1~10r/min adjustable, forward and reverse rotation, load capacity ≤35kg.
Chamber material: 304 stainless steel, inner shell 1.2mm, outer shell 1.5mm, water tank volume 200L, power supply 380V, rated power 10kW.
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- IPX9K高压喷淋试验箱的 CAS 号是多少？
- IPX9K高压喷淋试验箱的 CAS 号是 None。
- IPX9K高压喷淋试验箱的英文名称是什么？
- IPX9K高压喷淋试验箱的英文名称为 IPX9K High Pressure Spray Test Chamber。
- IPX9K高压喷淋试验箱还有哪些别名？
- IPX9K高压喷淋试验箱又称 高压喷淋试验箱、IPX9K喷淋试验箱。
- IPX9K高压喷淋试验箱有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条IPX9K高压喷淋试验箱供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- IPX9K高压喷淋试验箱的供应商主要分布在哪些地区？
- IPX9K高压喷淋试验箱的供应商主要分布在 上海市（1 条） 等地。
- IPX9K高压喷淋试验箱有哪些级别可选？
- 平台上IPX9K高压喷淋试验箱的供应级别包括 工业级。
- IPX9K高压喷淋试验箱的报价单位是什么？
- IPX9K高压喷淋试验箱的报价单位主要有 千克。
- 哪里可以查到IPX9K高压喷淋试验箱的价格？
- 掌上化工IPX9K高压喷淋试验箱产品页汇总了各供应商的最新报价与规格，地址：/chemicals/ipx9k-gao-ya-pen-lin-shi-yan-xiang/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
