集装箱标养室 (CAS No.None)

Product Name:Container Standard Curing Room

English Name:Container Standard Curing Room

Aliases:Container curing room, Mobile standard curing room, Concrete curing room, Construction site standard curing room

Physical Properties:The container standard curing room is a mobile curing facility. The overall dimensions are about 6m × 2.4m × 2.3m and it is divided into a control buffer room and a specimen placement room. It maintains the curing environment at 20±2°C and humidity ≥95%RH, and is equipped with heating, cooling, humidification and circulating air supply systems. A high-precision temperature/humidity sensor and automatic control system are adopted.

Uses:Used for standard curing of concrete test blocks, cement test blocks, mortar, thermal insulation materials, coatings, structural adhesives, etc. It meets the requirements of GB/T50081-2002 with temperature 20±2°C and humidity ≥95%RH. Suitable for construction, highway engineering and quality inspection units.

Technical Specifications:

Temperature control accuracy: 20±2°C, resolution 0.1°C; humidity control range ≥95%RH.

Power parameters: heating power 4000W, auxiliary water heating 1500W, ultrasonic humidification 350W, mechanical atomizing humidification 120W, nozzle atomizing humidification 50W, cooling 2000W, total operating power 6000W; power supply 220V/50Hz.

Humidification methods: ultrasonic atomization, mechanical atomization and nozzle atomization; automatic, intermittent and cyclic humidification modes are available.

Box size: 6-meter standard shipping container, approx. 2.4m × 6m × 2.3m, mobile and reusable.

Control system: digital temperature/humidity controller, automatic power-off protection against water shortage and dry heating, water shortage alarm, leakage protection, 6-channel separate control and status indication, sensor with delayed protection function.
