焦炭反应后强度测定仪 (CAS No.None)
- 中文别名
- 焦炭反应后强度测定仪；焦炭反应性测定仪；焦炭热强度测定仪
- 英文名称
- Coke Reactivity and Post-Reaction Strength Apparatus
- 所属类别
- 试剂实验设备
- 物化性质
- 该设备为立式机电一体化仪器，采用进口高温炉丝和西门子PLC控制，反应器由底部机械传动装卸。外形尺寸1000mm×850mm×1800mm，设备总重小于500kg。
- 技术参数
- 温度控制范围常温~1100℃，恒温精度1100℃±3℃，升温速率15℃/min可调。 气体流量采用质量流量控制器自动控制，N2和CO2流量均为0-10L可调，准确度±1.5%F.S。 反应器材质GH3044，内径Φ80mm，使用温度≤1400℃。 电炉额定功率7.5kW，三相五线制电源，使用温度≤1250℃。 I型转鼓Φ140mm×700mm，转速20±0.5r/min，600转自动控制。
English description（英文原文，共 1465 字符）
Product Name:Coke Reactivity and Post-Reaction Strength Apparatus
English Name:Coke Reactivity and Post-Reaction Strength Apparatus
Aliases:Coke Post-Reaction Strength Tester, Coke Reactivity Tester, Coke Thermal Strength Tester
Physical Properties:The apparatus is a vertical integrated electromechanical unit, featuring imported high-temperature furnace wire and Siemens PLC control. The reactor is loaded/unloaded by bottom mechanical transmission. Dimensions: 1000mm×850mm×1800mm; total weight: <500kg.
Uses:It is used to determine the reactivity and post-reaction strength of coke in a high-temperature carbon dioxide atmosphere, and is an important equipment for evaluating the thermal performance of coke. It is widely applied in ironmaking, coking, and metallurgical research institutions, providing a basis for quality inspection of coke for blast furnace ironmaking.
Technical Specifications:
Temperature control range: ambient to 1100℃, constant temperature accuracy at 1100℃±3℃, heating rate 15℃/min adjustable.
Gas flow is automatically controlled by mass flow controllers, with N2 and CO2 flow rates both adjustable from 0 to 10L, accuracy ±1.5% F.S.
Reactor material: GH3044, inner diameter Φ80mm, maximum service temperature ≤1400℃.
Electric furnace with rated power 7.5kW, three-phase five-wire power supply, maximum service temperature ≤1250℃.
Type I drum: Φ140mm×700mm, rotation speed 20±0.5r/min, automatic control for 600 revolutions.
English Name:Coke Reactivity and Post-Reaction Strength Apparatus
Aliases:Coke Post-Reaction Strength Tester, Coke Reactivity Tester, Coke Thermal Strength Tester
Physical Properties:The apparatus is a vertical integrated electromechanical unit, featuring imported high-temperature furnace wire and Siemens PLC control. The reactor is loaded/unloaded by bottom mechanical transmission. Dimensions: 1000mm×850mm×1800mm; total weight: <500kg.
Uses:It is used to determine the reactivity and post-reaction strength of coke in a high-temperature carbon dioxide atmosphere, and is an important equipment for evaluating the thermal performance of coke. It is widely applied in ironmaking, coking, and metallurgical research institutions, providing a basis for quality inspection of coke for blast furnace ironmaking.
Technical Specifications:
Temperature control range: ambient to 1100℃, constant temperature accuracy at 1100℃±3℃, heating rate 15℃/min adjustable.
Gas flow is automatically controlled by mass flow controllers, with N2 and CO2 flow rates both adjustable from 0 to 10L, accuracy ±1.5% F.S.
Reactor material: GH3044, inner diameter Φ80mm, maximum service temperature ≤1400℃.
Electric furnace with rated power 7.5kW, three-phase five-wire power supply, maximum service temperature ≤1250℃.
Type I drum: Φ140mm×700mm, rotation speed 20±0.5r/min, automatic control for 600 revolutions.
