静电测试仪FMX-004 (CAS No.None)
- 物化性质
- 外壳材质为导电性ABS树脂（灰色）；主机重量140g，含电池约170g；工作温度0-40℃，湿度0-60%RH；电源为9V干电池（006P）。
English description（英文原文，共 1388 字符）
Product Name:Electrostatic Meter FMX-004
English Name:Electrostatic Meter FMX-004
Physical Properties:Housing is made of conductive ABS resin (gray); main unit weight 140 g, approx. 170 g with battery; operating temperature 0-40°C, humidity 0-60% RH; power supplied by one 9V dry battery (006P).
Uses:Used for measuring surface electrostatic voltage and ion balance status. Widely applied in electrostatic management of electronic component manufacturing, semiconductor production lines, cleanrooms, and packaging industries to evaluate the effectiveness of antistatic measures and control electrostatic discharge risks.
Technical Specifications:
Measurement range: AUTO mode low range 0 to ±1.49 kV, high range ±1.0 to ±30.0 kV; LOW mode 0 to ±3.00 kV; HI mode 0 to ±30.0 kV; ion balance mode 0 to ±300 V.
Measuring distance 25 mm ± 0.5 mm, response time within 1 second, sampling rate 5 times/second, measurement accuracy ±10%.
Display: wide LCD digital and chart display showing voltage value and polarity, right (+) red LED lights up, left (-) blue LED lights up.
Power: one 9V dry battery (006P), continuous operation approx. 30 hours, auto power off after approx. 5 minutes of inactivity (can be disabled by holding POWER button).
Dimensions: main unit 115 mm × 73 mm × 25 mm, ion balance plate 123 mm × 73 mm × 25 mm; analog output 0 to ±3.0 V corresponding to each range.
English Name:Electrostatic Meter FMX-004
Physical Properties:Housing is made of conductive ABS resin (gray); main unit weight 140 g, approx. 170 g with battery; operating temperature 0-40°C, humidity 0-60% RH; power supplied by one 9V dry battery (006P).
Uses:Used for measuring surface electrostatic voltage and ion balance status. Widely applied in electrostatic management of electronic component manufacturing, semiconductor production lines, cleanrooms, and packaging industries to evaluate the effectiveness of antistatic measures and control electrostatic discharge risks.
Technical Specifications:
Measurement range: AUTO mode low range 0 to ±1.49 kV, high range ±1.0 to ±30.0 kV; LOW mode 0 to ±3.00 kV; HI mode 0 to ±30.0 kV; ion balance mode 0 to ±300 V.
Measuring distance 25 mm ± 0.5 mm, response time within 1 second, sampling rate 5 times/second, measurement accuracy ±10%.
Display: wide LCD digital and chart display showing voltage value and polarity, right (+) red LED lights up, left (-) blue LED lights up.
Power: one 9V dry battery (006P), continuous operation approx. 30 hours, auto power off after approx. 5 minutes of inactivity (can be disabled by holding POWER button).
Dimensions: main unit 115 mm × 73 mm × 25 mm, ion balance plate 123 mm × 73 mm × 25 mm; analog output 0 to ±3.0 V corresponding to each range.
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- 静电测试仪FMX-004的 CAS 号是多少？
- 静电测试仪FMX-004的 CAS 号是 None。
- 静电测试仪FMX-004的英文名称是什么？
- 静电测试仪FMX-004的英文名称为 Electrostatic Meter FMX-004。
- 静电测试仪FMX-004有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条静电测试仪FMX-004供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- 静电测试仪FMX-004的供应商主要分布在哪些地区？
- 静电测试仪FMX-004的供应商主要分布在 上海市（1 条） 等地。
- 静电测试仪FMX-004有哪些级别可选？
- 平台上静电测试仪FMX-004的供应级别包括 工业级。
- 静电测试仪FMX-004的报价单位是什么？
- 静电测试仪FMX-004的报价单位主要有 千克。
- 哪里可以查到静电测试仪FMX-004的价格？
- 掌上化工静电测试仪FMX-004产品页汇总了各供应商的最新报价与规格，地址：/chemicals/jing-dian-ce-shi-yi-fmx-004/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
