空气净化器测试仓 (CAS No.None)
- 物化性质
- 试验仓容积约30m³，尺寸为3400W×2500H×3500L（mm），泄漏率<0.05。舱体采用10mm钢化玻璃，内壁为不锈钢材质，配有日光灯、1.4m家用吊扇、试验台架、电源插座、采样孔和加样孔。空气循环装置包含循环风机、中效过滤器（效率60%）、高效过滤器（效率99.9%）及调节风阀。排气系统含轴流风机、风阀、可调节百叶窗等。
- 技术参数
- 循环风机风量1800m³/h，全压500Pa 轴流风机风量1000m³/h，全压300Pa 电压测量范围0~300V，精度±2V；电流测量范围0~20A，精度±0.2A 温度测量范围-20~50℃，精度±0.5℃；湿度测量范围10%~90%，精度±3% 泄漏率<0.05，舱体容积约30m³
English description（英文原文，共 1523 字符）
Product Name:Air Purifier Test Chamber
English Name:Air Purifier Test Chamber
Aliases:Air Purifier Test Cabin, Air Cleaner Test Chamber
Physical Properties:The test chamber has a volume of approximately 30 m³, with dimensions of 3400W×2500H×3500L (mm), and a leakage rate of <0.05. The chamber body is made of 10 mm tempered glass with stainless steel inner walls, equipped with fluorescent lamps, a 1.4 m household ceiling fan, test bench, power sockets, sampling ports, and injection ports. The air circulation system includes a circulation fan, medium-efficiency filter (efficiency 60%), high-efficiency filter (efficiency 99.9%), and regulating damper. The exhaust system consists of an axial fan, damper, adjustable louver, and waterproof louver.
Uses:Designed according to GB/T 18801-2008, this chamber is used to simulate pollutant removal tests for air purifiers. It supports natural decay tests and total decay tests, measuring particle concentration changes to calculate the natural decay constant and total decay constant, thereby evaluating the purification performance of air purifiers.
Technical Specifications:
Circulation fan airflow: 1800 m³/h, total pressure: 500 Pa
Axial fan airflow: 1000 m³/h, total pressure: 300 Pa
Voltage measurement range: 0–300 V, accuracy: ±2 V; current measurement range: 0–20 A, accuracy: ±0.2 A
Temperature measurement range: -20 to 50 °C, accuracy: ±0.5 °C; humidity measurement range: 10%–90%, accuracy: ±3%
Leakage rate: <0.05; chamber volume: approximately 30 m³
English Name:Air Purifier Test Chamber
Aliases:Air Purifier Test Cabin, Air Cleaner Test Chamber
Physical Properties:The test chamber has a volume of approximately 30 m³, with dimensions of 3400W×2500H×3500L (mm), and a leakage rate of <0.05. The chamber body is made of 10 mm tempered glass with stainless steel inner walls, equipped with fluorescent lamps, a 1.4 m household ceiling fan, test bench, power sockets, sampling ports, and injection ports. The air circulation system includes a circulation fan, medium-efficiency filter (efficiency 60%), high-efficiency filter (efficiency 99.9%), and regulating damper. The exhaust system consists of an axial fan, damper, adjustable louver, and waterproof louver.
Uses:Designed according to GB/T 18801-2008, this chamber is used to simulate pollutant removal tests for air purifiers. It supports natural decay tests and total decay tests, measuring particle concentration changes to calculate the natural decay constant and total decay constant, thereby evaluating the purification performance of air purifiers.
Technical Specifications:
Circulation fan airflow: 1800 m³/h, total pressure: 500 Pa
Axial fan airflow: 1000 m³/h, total pressure: 300 Pa
Voltage measurement range: 0–300 V, accuracy: ±2 V; current measurement range: 0–20 A, accuracy: ±0.2 A
Temperature measurement range: -20 to 50 °C, accuracy: ±0.5 °C; humidity measurement range: 10%–90%, accuracy: ±3%
Leakage rate: <0.05; chamber volume: approximately 30 m³
