KS107BG高频仿组织超声体模 (CAS No.None)
- 中文别名
- 超声体模；仿组织超声体模；高频超声检测体模
- 英文名称
- KS107BG High-Frequency Tissue-Mimicking Ultrasound Phantom
- 所属类别
- 试剂实验设备
- 物化性质
- TM材料声速为1540±10m/s（23±3℃），声衰减系数斜率为0.70±0.05dB/cm/MHz（23±3℃）。尼龙靶线直径为0.3±0.05mm，位置公差为±0.1mm。体模采用仿组织超声材料制成，声学特性与人体软组织相近，适用于高频超声成像系统性能检测。
- 技术参数
- 轴向分辨力靶群分别位于深度10、30、50、70mm处，每群中靶线中心垂直距离由上而下依次为3、2、1、0.5mm，水平距离均为1mm 侧向分辨力靶群分别位于深度10、30、50、70mm处，每群中靶线中心水平距离依次为4、3、2、1mm 盲区靶群相邻靶线中心横向间距均为10mm，至声窗距离分别为8、7、6、5、4、3、2mm 纵向靶群共含靶线12条，相邻两线中心距离均为10mm；横向靶群位于深度40mm处，相邻两线中心距离均为10mm 模拟病灶为3个圆柱形囊性结构，直径分别为2、4、6mm，柱轴均与靶线平行，轴心分别位于深度15、30、45mm处
English description（英文原文，共 2076 字符）
Product Name:KS107BG High-Frequency Tissue-Mimicking Ultrasound Phantom
English Name:KS107BG High-Frequency Tissue-Mimicking Ultrasound Phantom
Aliases:Ultrasound phantom, Tissue-mimicking ultrasound phantom, High-frequency ultrasonic testing phantom
Physical Properties:The TM material has a sound velocity of 1540±10 m/s (23±3°C) and an attenuation coefficient slope of 0.70±0.05 dB/cm/MHz (23±3°C). The nylon target wire diameter is 0.3±0.05 mm with a positional tolerance of ±0.1 mm. Made of tissue-mimicking material with acoustic properties similar to human soft tissue, this phantom is suitable for performance testing of high-frequency ultrasound imaging systems.
Uses:Designed for performance testing and quality control of high-frequency ultrasound diagnostic equipment, it enables evaluation of axial resolution, lateral resolution, dead zone range, and target group positioning accuracy. It is also applicable for resolution testing of ultrasound imaging systems, clinical quality assurance, and acoustic characteristic verification in research and teaching.
Technical Specifications:
Axial resolution target groups are located at depths of 10, 30, 50, and 70 mm; within each group, the vertical distances between target centers from top to bottom are 3, 2, 1, and 0.5 mm, with horizontal spacing of 1 mm
Lateral resolution target groups are located at depths of 10, 30, 50, and 70 mm; the horizontal distances between target centers in each group are 4, 3, 2, and 1 mm respectively
Dead zone target groups have transverse spacing of 10 mm between adjacent target centers, with distances to the acoustic window of 8, 7, 6, 5, 4, 3, and 2 mm
The longitudinal target group contains 12 target lines with 10 mm spacing between adjacent centers; the transverse target group is located at a depth of 40 mm with 10 mm spacing between adjacent centers
Three cylindrical cystic simulated lesions are embedded in the TM material, with diameters of 2, 4, and 6 mm; their axes are parallel to the target lines and centered at depths of 15, 30, and 45 mm respectively
English Name:KS107BG High-Frequency Tissue-Mimicking Ultrasound Phantom
Aliases:Ultrasound phantom, Tissue-mimicking ultrasound phantom, High-frequency ultrasonic testing phantom
Physical Properties:The TM material has a sound velocity of 1540±10 m/s (23±3°C) and an attenuation coefficient slope of 0.70±0.05 dB/cm/MHz (23±3°C). The nylon target wire diameter is 0.3±0.05 mm with a positional tolerance of ±0.1 mm. Made of tissue-mimicking material with acoustic properties similar to human soft tissue, this phantom is suitable for performance testing of high-frequency ultrasound imaging systems.
Uses:Designed for performance testing and quality control of high-frequency ultrasound diagnostic equipment, it enables evaluation of axial resolution, lateral resolution, dead zone range, and target group positioning accuracy. It is also applicable for resolution testing of ultrasound imaging systems, clinical quality assurance, and acoustic characteristic verification in research and teaching.
Technical Specifications:
Axial resolution target groups are located at depths of 10, 30, 50, and 70 mm; within each group, the vertical distances between target centers from top to bottom are 3, 2, 1, and 0.5 mm, with horizontal spacing of 1 mm
Lateral resolution target groups are located at depths of 10, 30, 50, and 70 mm; the horizontal distances between target centers in each group are 4, 3, 2, and 1 mm respectively
Dead zone target groups have transverse spacing of 10 mm between adjacent target centers, with distances to the acoustic window of 8, 7, 6, 5, 4, 3, and 2 mm
The longitudinal target group contains 12 target lines with 10 mm spacing between adjacent centers; the transverse target group is located at a depth of 40 mm with 10 mm spacing between adjacent centers
Three cylindrical cystic simulated lesions are embedded in the TM material, with diameters of 2, 4, and 6 mm; their axes are parallel to the target lines and centered at depths of 15, 30, and 45 mm respectively
