LD23系列微机控制电子试验机（台式机） (CAS No.None)
- 中文别名
- LD23系列电子试验机；微机控制电子万能试验机；台式电子万能试验机
- 英文名称
- LD23 Series Microcomputer-Controlled Electronic Testing Machine (Benchtop)
- 所属类别
- 试剂实验设备
- 物化性质
- 主机机架采用高精度预加载滚珠丝杠和高强度光杠框架结构，传动效率高、刚度大。配备高稳定性应变式力传感器及全数字闭环测控系统，实现高精度力值测量。变形测量系统兼容应变式电子引伸计与夹持式自动跟踪大变形测量系统，可满足金属和非金属材料的不同变形测量需求。采用进口全数字式交流伺服电机驱动，运行平稳、噪音低，并配有急停保护开关。
English description（英文原文，共 1803 字符）
Product Name:LD23 Series Microcomputer-Controlled Electronic Testing Machine (Benchtop)
English Name:LD23 Series Microcomputer-Controlled Electronic Testing Machine (Benchtop)
Aliases:LD23 Series Electronic Testing Machine, Microcomputer-Controlled Electronic Universal Testing Machine, Benchtop Electronic Universal Testing Machine
Physical Properties:The main frame adopts high-precision preloaded ball screws and a high-strength guide-rod framework, offering high transmission efficiency and rigidity. It is equipped with a high-stability strain-gauge force sensor and a full digital closed-loop measurement and control system for high-accuracy force measurement. The deformation measurement system integrates a strain-gauge extensometer and a clamping automatic-tracking large-deformation measurement system, accommodating both metallic and non-metallic materials. Driven by an imported all-digital AC servo motor, the system operates smoothly with low noise and is equipped with an emergency stop switch for safety.
Uses:It is mainly used for tensile, compression, peeling, and tearing tests on metal wires, metal foils, films, paper, and other materials. It can measure the physical properties of materials according to national standards, international standards, or user-specified standards, and output test reports and characteristic curves.
Technical Specifications:
Force measurement range: 0.4%-100%FS (class 0.5) / 0.2%-100%FS (class 1), without range switching.
Relative error of force indication: within ±0.5% (class 0.5) / ±1.0% (class 1).
Crosshead speed adjustment range: 0.001-500mm/min, relative error of speed indication within ±0.2% of set value.
Displacement resolution: up to 0.05μm.
Effective test width: 340mm; overall dimensions: 620×460×1530mm; weight: about 100kg.
English Name:LD23 Series Microcomputer-Controlled Electronic Testing Machine (Benchtop)
Aliases:LD23 Series Electronic Testing Machine, Microcomputer-Controlled Electronic Universal Testing Machine, Benchtop Electronic Universal Testing Machine
Physical Properties:The main frame adopts high-precision preloaded ball screws and a high-strength guide-rod framework, offering high transmission efficiency and rigidity. It is equipped with a high-stability strain-gauge force sensor and a full digital closed-loop measurement and control system for high-accuracy force measurement. The deformation measurement system integrates a strain-gauge extensometer and a clamping automatic-tracking large-deformation measurement system, accommodating both metallic and non-metallic materials. Driven by an imported all-digital AC servo motor, the system operates smoothly with low noise and is equipped with an emergency stop switch for safety.
Uses:It is mainly used for tensile, compression, peeling, and tearing tests on metal wires, metal foils, films, paper, and other materials. It can measure the physical properties of materials according to national standards, international standards, or user-specified standards, and output test reports and characteristic curves.
Technical Specifications:
Force measurement range: 0.4%-100%FS (class 0.5) / 0.2%-100%FS (class 1), without range switching.
Relative error of force indication: within ±0.5% (class 0.5) / ±1.0% (class 1).
Crosshead speed adjustment range: 0.001-500mm/min, relative error of speed indication within ±0.2% of set value.
Displacement resolution: up to 0.05μm.
Effective test width: 340mm; overall dimensions: 620×460×1530mm; weight: about 100kg.
