LHSY-1.5B低温沥青延伸度测量仪 (CAS No.None)
- 中文别名
- 沥青延度试验仪；沥青延伸度测定仪；低温沥青延伸度仪
- 英文名称
- LHSY-1.5B Low-Temperature Asphalt Ductility Tester
- 所属类别
- 试剂实验设备
- 物化性质
- 本仪器依据JTG E20-2011《公路工程沥青及沥青混合料试验规程》中T 0605-2011《沥青延度试验》及GB/T 4508-2010标准设计制造，用于测定石油沥青在规定条件、一定温度下以一定速度拉伸至断裂时的长度（单位：mm）。试验槽内无丝杠、导轨等装置，试样安装方便，拉伸长度1.5m。恒温水槽采用304不锈钢双层设计，设有循环水槽及静水槽，静水槽内水温均匀无流动。采用伺服电机传动，拉伸过程平稳同步、速度均匀无抖动，配备高精度液晶温控仪，控温精度±0.1℃，轻触键控制，防水耐用。
English description（英文原文，共 1910 字符）
Product Name:LHSY-1.5B Low-Temperature Asphalt Ductility Tester
English Name:LHSY-1.5B Low-Temperature Asphalt Ductility Tester
Aliases:Asphalt Ductility Testing Apparatus, Bitumen Ductility Tester, Low-Temperature Asphalt Extension Tester
Physical Properties:This instrument is designed in accordance with T 0605-2011 "Asphalt Ductility Test" from JTG E20-2011 "Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering" and GB/T 4508-2010. It is used to measure the length (in mm) at which petroleum asphalt breaks when stretched at a specified speed and temperature. The test tank is free of lead screws and guide rails, facilitating easy specimen mounting, with a stretching length of 1.5 m. The constant-temperature water bath features a 304 stainless steel double-layer design with both circulating and static water tanks, ensuring uniform and still water temperature. The servo motor drive provides smooth, synchronized stretching with uniform speed and no vibration. A high-precision LCD temperature controller with an accuracy of ±0.1°C and touch keys is waterproof, durable, and easy to clean.
Uses:Suitable for measuring the ductility of various grades of asphalt, residues from distillation of liquid asphalt, and evaporation residues of asphalt emulsions. It features automatic temperature control, continuously variable speed, and simultaneous testing of three molds. Widely used in production, road construction, and scientific research, especially for modified asphalt testing.
Technical Specifications:
Working measurement length: 1500mm
Tensile slider speeds: 10mm/min, 50mm/min
Water bath temperature control range: 0–50°C; temperature resolution 0.01°C; temperature control accuracy ±0.1°C
Stirring pump: 45W; heating power: 2KW; refrigeration power: 2KW; cooling capacity: 4000 cal/min
Power supply: 220V, 50HZ; dimensions: 210×44×98(cm); net weight: 210Kg
English Name:LHSY-1.5B Low-Temperature Asphalt Ductility Tester
Aliases:Asphalt Ductility Testing Apparatus, Bitumen Ductility Tester, Low-Temperature Asphalt Extension Tester
Physical Properties:This instrument is designed in accordance with T 0605-2011 "Asphalt Ductility Test" from JTG E20-2011 "Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering" and GB/T 4508-2010. It is used to measure the length (in mm) at which petroleum asphalt breaks when stretched at a specified speed and temperature. The test tank is free of lead screws and guide rails, facilitating easy specimen mounting, with a stretching length of 1.5 m. The constant-temperature water bath features a 304 stainless steel double-layer design with both circulating and static water tanks, ensuring uniform and still water temperature. The servo motor drive provides smooth, synchronized stretching with uniform speed and no vibration. A high-precision LCD temperature controller with an accuracy of ±0.1°C and touch keys is waterproof, durable, and easy to clean.
Uses:Suitable for measuring the ductility of various grades of asphalt, residues from distillation of liquid asphalt, and evaporation residues of asphalt emulsions. It features automatic temperature control, continuously variable speed, and simultaneous testing of three molds. Widely used in production, road construction, and scientific research, especially for modified asphalt testing.
Technical Specifications:
Working measurement length: 1500mm
Tensile slider speeds: 10mm/min, 50mm/min
Water bath temperature control range: 0–50°C; temperature resolution 0.01°C; temperature control accuracy ±0.1°C
Stirring pump: 45W; heating power: 2KW; refrigeration power: 2KW; cooling capacity: 4000 cal/min
Power supply: 220V, 50HZ; dimensions: 210×44×98(cm); net weight: 210Kg
