莲蓬式淋雨试验箱（手持式洒水） (CAS No.None)
- 物化性质
- 设备由立柱、莲蓬式洒水头、可调节挡水板及可调节水流系统四部分组成。立柱、洒水头及挡水板均采用SUS304不锈钢制造，底座为圆盘式；喷水孔为激光打孔，喷水角度可调。水压控制系统采用流量计调节压力，配备泄压手动调节水阀和水过滤器；需配备贮水池及吸水电机，以提供规定流量和压力的试验用水。试验用水不循环使用。
English description（英文原文，共 1671 字符）
Product Name:Hand-held Shower Rain Test Chamber
English Name:Hand-held Shower Rain Test Chamber
Aliases:Shower-head rain test equipment, Hand-held spray rain test equipment
Physical Properties:The equipment consists of four parts: a support column, a lotus-head water sprayer, an adjustable water baffle plate, and an adjustable water flow system. The column, sprayer and baffle plate are made of SUS304 stainless steel with a disc-type base. The spray holes are laser-drilled and the spray angle is adjustable. The water pressure control system uses a flowmeter to regulate pressure, and is equipped with a manual pressure-relief water valve and a water filter. A water storage tank and a suction pump are required to supply test water at the specified flow rate and pressure. Test water is not recirculated.
Uses:Used for artificial simulated rain testing of enclosures and seals of electrical and electronic products, to verify their waterproof performance and working reliability during or after the water test. It can fully simulate external rain environments and reproduce their effects on products, making it suitable for scientific research, product development and quality control. This equipment does not cover heavy rainfall with strong wind speed, nor does it consider water ingress caused by the temperature difference between the test sample and the rainwater.
Technical Specifications:
Model: JL-1
Spray nozzle diameter: φ0.5mm; number of spray holes: 121; spray outlet diameter: φ100mm
Spray water pressure: 30-100kPa
Spray angle: adjustable from 0° to 45°
Applicable standards: GB 2423.38-2005, GB/T4942.2-93, GB 4208-93, GB 4706, GB 7000, etc.
English Name:Hand-held Shower Rain Test Chamber
Aliases:Shower-head rain test equipment, Hand-held spray rain test equipment
Physical Properties:The equipment consists of four parts: a support column, a lotus-head water sprayer, an adjustable water baffle plate, and an adjustable water flow system. The column, sprayer and baffle plate are made of SUS304 stainless steel with a disc-type base. The spray holes are laser-drilled and the spray angle is adjustable. The water pressure control system uses a flowmeter to regulate pressure, and is equipped with a manual pressure-relief water valve and a water filter. A water storage tank and a suction pump are required to supply test water at the specified flow rate and pressure. Test water is not recirculated.
Uses:Used for artificial simulated rain testing of enclosures and seals of electrical and electronic products, to verify their waterproof performance and working reliability during or after the water test. It can fully simulate external rain environments and reproduce their effects on products, making it suitable for scientific research, product development and quality control. This equipment does not cover heavy rainfall with strong wind speed, nor does it consider water ingress caused by the temperature difference between the test sample and the rainwater.
Technical Specifications:
Model: JL-1
Spray nozzle diameter: φ0.5mm; number of spray holes: 121; spray outlet diameter: φ100mm
Spray water pressure: 30-100kPa
Spray angle: adjustable from 0° to 45°
Applicable standards: GB 2423.38-2005, GB/T4942.2-93, GB 4208-93, GB 4706, GB 7000, etc.
