迷你型全自动Gentier MINI分析系统检测设备 (CAS No.None)

Product Name:Mini Fully Automatic Gentier MINI Analysis System Detection Equipment

English Name:Mini Fully Automatic Gentier MINI Analysis System Detection Equipment

Aliases:Real-time Fluorescence Quantitative PCR Detection System, Miniature Fluorescence Quantitative Analyzer, Portable PCR Detection Equipment

Physical Properties:Compact and portable design with overall dimensions of approximately 200mm×140mm×100mm and a weight of about 2.5kg. Equipped with a high-resolution color touchscreen and USB/network interfaces, it can independently perform real-time fluorescence quantitative PCR amplification and data analysis after nucleic acid extraction.

Uses:It is used for real-time fluorescence quantitative PCR detection of nucleic acids, enabling rapid qualitative and quantitative analysis of targets such as pathogens and gene expression. It is suitable for clinical diagnosis, food safety testing, animal disease prevention and control, and other fields.

Technical Specifications:

Capable of detecting 16×0.2 mL PCR tubes (individual tubes or 8-tube strips) simultaneously.

Dual-channel fluorescence detection, compatible with common fluorescent dyes such as FAM/HEX (VIC).

Temperature control range: 4°C to 99°C, maximum heating rate ≥4°C/s, temperature accuracy ±0.3°C.

Detection sensitivity: capable of detecting single-copy nucleic acid templates.

Data analysis: supports absolute quantification, relative quantification, melting curve analysis, and SNP analysis.
