模压非球面光学玻璃镜片退火炉 (CAS No.None)
- 中文别名
- 精密退火炉；模压玻璃镜片退火炉；光学玻璃退火炉；保护气氛退火炉
- 英文名称
- Annealing Furnace for Molded Aspherical Optical Glass Lenses
- 所属类别
- 试剂实验设备
- 物化性质
- 炉体采用镀锌板外壳（RAL7035）并内箱加固；高温区炉胆由310S不锈钢板折弯焊接而成；隔热层为多晶氧化铝陶瓷纤维棉；加热元件为HRE电阻丝，分布于炉膛下、左、右四面；配备耐高温热风循环风机实现炉内热量循环均热；炉门硅胶圈压紧密封，无需水冷；进气口配8mm气管接头，流量0-15L/min可调。
- 技术参数
- 整机功率12KW，电源380V/50Hz，温度测量采用K分度热电偶。 使用温度700℃，长期使用温度400-700℃，温度波动度±1℃，显示精度0.1℃，均热罩内10点测温温差±3℃。 有效加热尺寸300×400×400mm（长×宽×高），容积50L，炉内水平4层活动抽拉式耐热不锈钢隔板。 升温速度≥85℃/h，降温速率≥50℃/h（350℃以上），均可任意调节。 配备触摸屏可编程控制系统，PID调节，可设置30段温度曲线；具备过载/过流/过压保护及超温、热电偶异常报警，炉门未关紧无法启动加热。
English description（英文原文，共 2212 字符）
Product Name:Annealing Furnace for Molded Aspherical Optical Glass Lenses
English Name:Annealing Furnace for Molded Aspherical Optical Glass Lenses
Aliases:Precision Annealing Furnace, Molded Glass Lens Annealing Furnace, Optical Glass Annealing Furnace, Protective Atmosphere Annealing Furnace
Physical Properties:The furnace body features a galvanized steel shell (RAL7035) with reinforced inner chamber; the hot zone is fabricated from bent and welded 310S stainless steel plates; thermal insulation is made of polycrystalline alumina ceramic fiber wool; HRE resistance wires are used as heating elements, arranged on the lower, left and right sides of the chamber. A high-temperature hot-air circulation fan ensures uniform heat distribution inside the furnace; the door is sealed by a compressed silicone rubber ring requiring no water cooling; the gas inlet is equipped with an 8mm tube connector with adjustable flow rate of 0-15 L/min.
Uses:Used for precision annealing of molded aspherical optical glass lenses, suitable for molded glass lenses of various apertures used in mobile phones, DSLR cameras, security surveillance, and autonomous driving vehicle cameras. Annealing experiments can be performed under atmospheres of nitrogen, argon, air, or carbon dioxide; also applicable to annealing processes of special materials requiring a protective gas environment.
Technical Specifications:
Total power 12kW, power supply 380V/50Hz, temperature measurement by K-type thermocouple.
Operating temperature up to 700℃, long-term service temperature 400-700℃, temperature fluctuation ±1℃, display resolution 0.1℃, temperature difference within ±3℃ measured at 10 points inside the soaking cover.
Effective heating chamber dimensions 300×400×400mm (L×W×H), volume 50L, with 4 horizontal pull-out heat-resistant stainless steel shelves.
Heating rate ≥85℃/h, cooling rate ≥50℃/h (above 350℃), both infinitely adjustable.
Equipped with a touchscreen programmable control system, PID adjustment, supports up to 30-segment temperature curves; features overload/overcurrent/overvoltage protection and over-temperature/thermocouple fault alarms; heating cannot be started if the door is not fully closed.
English Name:Annealing Furnace for Molded Aspherical Optical Glass Lenses
Aliases:Precision Annealing Furnace, Molded Glass Lens Annealing Furnace, Optical Glass Annealing Furnace, Protective Atmosphere Annealing Furnace
Physical Properties:The furnace body features a galvanized steel shell (RAL7035) with reinforced inner chamber; the hot zone is fabricated from bent and welded 310S stainless steel plates; thermal insulation is made of polycrystalline alumina ceramic fiber wool; HRE resistance wires are used as heating elements, arranged on the lower, left and right sides of the chamber. A high-temperature hot-air circulation fan ensures uniform heat distribution inside the furnace; the door is sealed by a compressed silicone rubber ring requiring no water cooling; the gas inlet is equipped with an 8mm tube connector with adjustable flow rate of 0-15 L/min.
Uses:Used for precision annealing of molded aspherical optical glass lenses, suitable for molded glass lenses of various apertures used in mobile phones, DSLR cameras, security surveillance, and autonomous driving vehicle cameras. Annealing experiments can be performed under atmospheres of nitrogen, argon, air, or carbon dioxide; also applicable to annealing processes of special materials requiring a protective gas environment.
Technical Specifications:
Total power 12kW, power supply 380V/50Hz, temperature measurement by K-type thermocouple.
Operating temperature up to 700℃, long-term service temperature 400-700℃, temperature fluctuation ±1℃, display resolution 0.1℃, temperature difference within ±3℃ measured at 10 points inside the soaking cover.
Effective heating chamber dimensions 300×400×400mm (L×W×H), volume 50L, with 4 horizontal pull-out heat-resistant stainless steel shelves.
Heating rate ≥85℃/h, cooling rate ≥50℃/h (above 350℃), both infinitely adjustable.
Equipped with a touchscreen programmable control system, PID adjustment, supports up to 30-segment temperature curves; features overload/overcurrent/overvoltage protection and over-temperature/thermocouple fault alarms; heating cannot be started if the door is not fully closed.
