纳米速度浸渍提拉镀膜机 (CAS No.None)
- 物化性质
- 设备采用触控面板操作，支持双轴同步和单轴独立运动，可对玻璃、有机玻璃、铜箔、管状材料等基材进行纳米级浸渍提拉镀膜。提拉速度以1nm为单位可调，最大速度60mm/s，适用于纳米级薄膜、蛋白石薄膜的形成和粒子阵列的生成。
English description（英文原文，共 1485 字符）
Product Name:Nano-speed Dip Coater
English Name:Nano-speed Dip Coater
Aliases:Dip Coating Instrument, Vertical Dip Coater, Nano-scale Dip Coating Machine
Physical Properties:The equipment features touch panel operation and supports simultaneous dual-axis or independent single-axis motion. It can perform nano-scale dip coating on substrates such as glass, acrylic, copper foil, and tubular materials. The dipping speed is adjustable in 1 nm increments, with a maximum speed of 60 mm/s. It is suitable for forming nano-scale thin films, opal films, and particle arrays.
Uses:Primarily used in liquid-phase methods such as sol-gel for preparing thin film materials. By vertically immersing the substrate into the coating solution and withdrawing it at low speed, a continuous and uniform nano-scale film is formed on the substrate surface. It is applicable for producing nano thin films, opal films, and particle arrays.
Technical Specifications:
Travel: Z-axis 100 mm, X-axis 100 mm.
Dipping speed range: 1 nm/s to 60 mm/s, adjustable in 1 nm increments.
Touch panel operation with English/Japanese display switchable by one touch; supports up to 16 speed change points, 16 stop positions, 16 stop times, and stores up to 8 programs.
Features continuous operation, manual operation, and repeat operation; supports simultaneous dual-axis and independent single-axis operation.
Power supply: AC100V, 300VA; max load 500g; max processing size 100mm(H); dimensions 442×250×451mm.
English Name:Nano-speed Dip Coater
Aliases:Dip Coating Instrument, Vertical Dip Coater, Nano-scale Dip Coating Machine
Physical Properties:The equipment features touch panel operation and supports simultaneous dual-axis or independent single-axis motion. It can perform nano-scale dip coating on substrates such as glass, acrylic, copper foil, and tubular materials. The dipping speed is adjustable in 1 nm increments, with a maximum speed of 60 mm/s. It is suitable for forming nano-scale thin films, opal films, and particle arrays.
Uses:Primarily used in liquid-phase methods such as sol-gel for preparing thin film materials. By vertically immersing the substrate into the coating solution and withdrawing it at low speed, a continuous and uniform nano-scale film is formed on the substrate surface. It is applicable for producing nano thin films, opal films, and particle arrays.
Technical Specifications:
Travel: Z-axis 100 mm, X-axis 100 mm.
Dipping speed range: 1 nm/s to 60 mm/s, adjustable in 1 nm increments.
Touch panel operation with English/Japanese display switchable by one touch; supports up to 16 speed change points, 16 stop positions, 16 stop times, and stores up to 8 programs.
Features continuous operation, manual operation, and repeat operation; supports simultaneous dual-axis and independent single-axis operation.
Power supply: AC100V, 300VA; max load 500g; max processing size 100mm(H); dimensions 442×250×451mm.
