纳米压痕仪 (CAS No.None)
- 物化性质
- 通过力与压入深度的曲线计算材料力学性能，无需显微镜观察压痕面积；支持划痕法（声发射、划痕位移、摩擦力传感器及视频显微镜）和连续刚度模式，可获得硬度随压入深度变化的数据。
- 技术参数
- 样品要求为圆柱体或方形，直径3-30mm，高度0-10mm。 样品上下面平行，测试面抛光，无肉眼可见划痕。 薄膜样品需制样，不规则或过小样品需用硬树脂镶嵌后抛光处理。 普通硬度模量测试提供5个数据点；硬度25-30GPa每样提供5个数据点；硬度30-35GPa每样提供3个数据点。 测试杨氏模量需提供泊松比，通过弹性模量换算得到。
English description（英文原文，共 1296 字符）
Product Name:Nanoindenter
English Name:Nanoindenter
Physical Properties:Mechanical properties are calculated from the force-indentation depth curve without the need for microscopic observation of the indentation area. It supports scratch testing (with acoustic emission, scratch displacement, friction sensors and video microscopy) and continuous stiffness mode, enabling hardness variation with indentation depth to be obtained.
Uses:Used to test the adhesion strength of thin films or coatings, study wear or removal mechanisms of materials, and is widely applied in the measurement of hardness, elastic modulus, toughness, coating strength, and fracture toughness.
Technical Specifications:
Samples should be cylindrical or square, with a diameter of 3-30 mm and a height of 0-10 mm.
The top and bottom surfaces of the sample must be parallel, and the test surface should be polished with no visible scratches.
Thin film samples require proper preparation; irregular or undersized samples need to be mounted in hard resin and polished.
Standard hardness/modulus testing provides 5 data points; for hardness of 25-30 GPa, 5 data points per sample; for hardness of 30-35 GPa, 3 data points per sample.
Poisson's ratio must be provided to obtain Young's modulus from the elastic modulus.
English Name:Nanoindenter
Physical Properties:Mechanical properties are calculated from the force-indentation depth curve without the need for microscopic observation of the indentation area. It supports scratch testing (with acoustic emission, scratch displacement, friction sensors and video microscopy) and continuous stiffness mode, enabling hardness variation with indentation depth to be obtained.
Uses:Used to test the adhesion strength of thin films or coatings, study wear or removal mechanisms of materials, and is widely applied in the measurement of hardness, elastic modulus, toughness, coating strength, and fracture toughness.
Technical Specifications:
Samples should be cylindrical or square, with a diameter of 3-30 mm and a height of 0-10 mm.
The top and bottom surfaces of the sample must be parallel, and the test surface should be polished with no visible scratches.
Thin film samples require proper preparation; irregular or undersized samples need to be mounted in hard resin and polished.
Standard hardness/modulus testing provides 5 data points; for hardness of 25-30 GPa, 5 data points per sample; for hardness of 30-35 GPa, 3 data points per sample.
Poisson's ratio must be provided to obtain Young's modulus from the elastic modulus.
