平面平晶 60mm 一级光学平面平晶 (CAS No.None)

Product Name:Optical Flat

English Name:Optical Flat

Aliases:Plane Optical Flat, Optical Planar Flat, Grade 1 Optical Flat

Physical Properties:An optical flat is a cylindrical gauge with two (or one) optical measuring surfaces, made of optical glass or fused quartz. The optical measuring surface has extremely low surface roughness and flatness error and can generate light-wave interference fringes. Grade 1 optical flats have a flatness error of 0.03–0.05 μm. The 60 mm flat typically has a thickness of 20 mm and a mirror-like working surface.

Uses:The plane optical flat is based on the principle of light-wave interference. The interference fringes formed between its measuring surface and the test surface are used to measure flatness error. It is used to verify the wringing quality and flatness of gauge blocks, and to check the flatness of measuring and working surfaces of instruments, gauges, and high-precision flat parts such as optical components, platforms, surface plates, guide rails, and seals. It is especially suitable as a standard reference plane and master flat in metrology institutes and laboratories.

Technical Specifications:

Diameter (mm): 60

Grade: Grade 1

Flatness error of working surface (μm): ≤0.05

Surface roughness Ra (μm): ≤0.01

Material: optical glass or fused quartz
