热风循环石墨舟烘箱 (CAS No.None)
- 物化性质
- 该设备为热风循环干燥设备，内胆采用SUS316不锈钢板焊接制作，内壁喷涂耐高温特氟龙防腐涂层，外壁静电喷塑。工作温度范围为常温至250℃，控温灵敏度±1℃，升温速度3~4℃/min。采用垂直送风方式，热风由箱体内左右两侧导流口出风，中间吸风。
English description（英文原文，共 1506 字符）
Product Name:Hot Air Circulation Oven for Graphite Boats
English Name:Hot Air Circulation Oven for Graphite Boats
Aliases:Graphite Boat Oven, Hot Air Circulation Drying Oven, Graphite Boat Dryer
Physical Properties:This equipment is a hot air circulation drying device. The inner chamber is made of SUS316 stainless steel plates with high-temperature Teflon anti-corrosion coating on the inner wall and electrostatic plastic spraying on the outer wall. The working temperature ranges from room temperature to 250°C with a temperature control sensitivity of ±1°C and a heating rate of 3-4°C/min. It adopts vertical air supply, with hot air discharged from the guide outlets on both sides of the chamber and sucked from the middle.
Uses:It is mainly used for drying silicon materials such as polycrystalline silicon, monocrystalline silicon, silicon wafers and silicon rods after acid washing in the solar PV industry, and is also widely used for heating and drying after acid or alkali washing. After cleaning, graphite boats are dried by hot air circulation with automatic control of the whole process, improving drying efficiency and corrosion resistance.
Technical Specifications:
Internal dimensions: 1500*2600*1400mm (depth*width*height)
External dimensions: 1900*3160*2200mm (depth*width*height)
Working temperature: room temperature to 250°C, adjustable; temperature control sensitivity: ±1°C
Heating rate: 3-4°C/min
Blower motor: 380V, installed on the top of the oven; vertical air supply
English Name:Hot Air Circulation Oven for Graphite Boats
Aliases:Graphite Boat Oven, Hot Air Circulation Drying Oven, Graphite Boat Dryer
Physical Properties:This equipment is a hot air circulation drying device. The inner chamber is made of SUS316 stainless steel plates with high-temperature Teflon anti-corrosion coating on the inner wall and electrostatic plastic spraying on the outer wall. The working temperature ranges from room temperature to 250°C with a temperature control sensitivity of ±1°C and a heating rate of 3-4°C/min. It adopts vertical air supply, with hot air discharged from the guide outlets on both sides of the chamber and sucked from the middle.
Uses:It is mainly used for drying silicon materials such as polycrystalline silicon, monocrystalline silicon, silicon wafers and silicon rods after acid washing in the solar PV industry, and is also widely used for heating and drying after acid or alkali washing. After cleaning, graphite boats are dried by hot air circulation with automatic control of the whole process, improving drying efficiency and corrosion resistance.
Technical Specifications:
Internal dimensions: 1500*2600*1400mm (depth*width*height)
External dimensions: 1900*3160*2200mm (depth*width*height)
Working temperature: room temperature to 250°C, adjustable; temperature control sensitivity: ±1°C
Heating rate: 3-4°C/min
Blower motor: 380V, installed on the top of the oven; vertical air supply
共 1 家生产厂家、批发商，
1 条供应报价
供应报价
常见问题
- 热风循环石墨舟烘箱的 CAS 号是多少？
- 热风循环石墨舟烘箱的 CAS 号是 None。
- 热风循环石墨舟烘箱的英文名称是什么？
- 热风循环石墨舟烘箱的英文名称为 Hot Air Circulation Oven for Graphite Boats。
- 热风循环石墨舟烘箱还有哪些别名？
- 热风循环石墨舟烘箱又称 石墨舟烘箱、热风循环烘箱、石墨舟干燥箱。
- 热风循环石墨舟烘箱有哪些供应商和生产厂家？
- 掌上化工当前收录 1 条热风循环石墨舟烘箱供应报价，来自 1 家供应商，可按地区、纯度、级别筛选对比。
- 热风循环石墨舟烘箱的供应商主要分布在哪些地区？
- 热风循环石墨舟烘箱的供应商主要分布在 上海市（1 条） 等地。
- 热风循环石墨舟烘箱有哪些级别可选？
- 平台上热风循环石墨舟烘箱的供应级别包括 工业级。
- 热风循环石墨舟烘箱的报价单位是什么？
- 热风循环石墨舟烘箱的报价单位主要有 千克。
- 哪里可以查到热风循环石墨舟烘箱的价格？
- 掌上化工热风循环石墨舟烘箱产品页汇总了各供应商的最新报价与规格，地址：/chemicals/re-feng-xun-huan-shi-mo-zhou-hong-xiang/。部分供应商价格为电议，可通过页面上的询价功能直接获取。
