SHBY-60B型恒温恒湿养护箱（全不锈钢） (CAS No.None)

Product Name:SHBY-60B Constant Temperature and Humidity Curing Box (All Stainless Steel)

English Name:SHBY-60B Constant Temperature and Humidity Curing Box (All Stainless Steel)

Aliases:Constant temperature and humidity curing box, All stainless steel curing box, SHBY-60B curing box

Physical Properties:The box body is composed of three layers: inner, middle and outer. The outer shell and inner liner are welded from stainless steel, and the middle interlayer is filled with high-quality thermal insulation material. The shelves are made of high-quality stainless steel tubes. Ultrasonic humidification is adopted, and the humidifying device is automatically controlled by the humidity controller.

Uses:It is mainly used for standard curing of cement, concrete and building test specimens under constant temperature and humidity. The temperature controller automatically controls heating and cooling to maintain the cabinet temperature; the ultrasonic humidifier cooperates with the humidity controller to automatically humidify and keep the humidity above RH92%, meeting the requirements of relevant curing standards.

Technical Specifications:

Instrument accuracy: ±0.1℃; temperature difference inside box: ≤±1℃.

Controlled humidity: above RH92% (adjustable); factory default settings: temperature 20.0±1℃, humidity 95±2%.

Power supply: ~220V; heating power: 1000W; cooling power: 200W; humidifying power: 55W; fan: 220V 30W.

Humidification capacity: 400 mL/h; humidifier tank volume: 5.5L; water level in bottom heating tank: 120mm-140mm.

Effective internal dimensions: 1330×530×1000mm; working environment temperature: 0-40℃.
