石墨烯还原炉真空气氛炉 (CAS No.None)
- 物化性质
- 该设备利用微波分子震荡加热特性，使介质内外一致剧烈升温，实现瞬间膨化。内腔为不锈钢，外壳碳钢喷塑；采用三通高硼硅玻璃管作为盛料结构；微波频率2450MHz，功率4KW，可实现0~4KW线性无级调节；微波泄漏量<5mW/cm²。
English description（英文原文，共 1164 字符）
Product Name:Graphene Reduction Furnace Vacuum Atmosphere Furnace
English Name:Graphene Reduction Furnace Vacuum Atmosphere Furnace
Aliases:MKG Series Microwave Atmosphere Furnace, Graphene Expansion Furnace
Physical Properties:This equipment utilizes microwave molecular oscillation heating to uniformly and rapidly raise the temperature inside and outside the medium, achieving instantaneous expansion. The inner chamber is made of stainless steel, and the outer shell is carbon steel with plastic spraying. A three-way borosilicate glass tube is used as the material container. The microwave frequency is 2450MHz with a power of 4KW, steplessly adjustable from 0 to 4KW. The microwave leakage is less than 5mW/cm².
Uses:Suitable for the production of expanded graphite, as well as processes such as high-temperature pyrolysis, carbonization, and ashing.
Technical Specifications:
Input power: three-phase 380V, 50Hz
Rated power: >7.5KVA
Equipment dimensions: approx. 1200×600×1000mm (H×W×D)
Chamber dimensions: approx. 400×400×400mm (W×H×D)
Glass tube dimensions: horizontal tube length 700mm, diameter 230mm; vertical tube length 275mm, diameter 81mm
English Name:Graphene Reduction Furnace Vacuum Atmosphere Furnace
Aliases:MKG Series Microwave Atmosphere Furnace, Graphene Expansion Furnace
Physical Properties:This equipment utilizes microwave molecular oscillation heating to uniformly and rapidly raise the temperature inside and outside the medium, achieving instantaneous expansion. The inner chamber is made of stainless steel, and the outer shell is carbon steel with plastic spraying. A three-way borosilicate glass tube is used as the material container. The microwave frequency is 2450MHz with a power of 4KW, steplessly adjustable from 0 to 4KW. The microwave leakage is less than 5mW/cm².
Uses:Suitable for the production of expanded graphite, as well as processes such as high-temperature pyrolysis, carbonization, and ashing.
Technical Specifications:
Input power: three-phase 380V, 50Hz
Rated power: >7.5KVA
Equipment dimensions: approx. 1200×600×1000mm (H×W×D)
Chamber dimensions: approx. 400×400×400mm (W×H×D)
Glass tube dimensions: horizontal tube length 700mm, diameter 230mm; vertical tube length 275mm, diameter 81mm
