时效炉 铝合金时效炉 铝合金热处理炉 (CAS No.None)
- 物化性质
- 设备为双风道循环式水平送风结构，采用耐高温长轴电动机带动离心风叶，热风循环避免炉体内存在温度死角。保温层采用1260标准型硅酸铝纤维填充，厚度120mm，保温性能良好。加热系统采用U型不锈钢管状加热元件，连续使用寿命长。工作温度范围为室温至300℃，温控精度±1℃。
English description（英文原文，共 1628 字符）
Product Name:Aging Furnace for Aluminum Alloy
English Name:Aging Furnace for Aluminum Alloy
Aliases:Aging Oven, Aluminum Alloy Heat Treatment Furnace
Physical Properties:The equipment features a dual-air-duct circulating horizontal air supply structure, using high-temperature-resistant long-shaft motors driving centrifugal fans to ensure uniform hot air circulation and eliminate temperature dead zones in the furnace chamber. The insulation layer is filled with 1260 standard alumina silicate fiber with a thickness of 120mm, providing excellent thermal insulation. The heating system adopts U-shaped stainless steel tubular heating elements with long continuous service life. Working temperature range is room temperature to 300°C with temperature control accuracy of ±1°C.
Uses:Mainly used for artificial aging treatment of aluminum alloy products. Through precise temperature control heating, it homogenizes the internal structure of aluminum alloy materials, eliminates processing stress, and improves material hardness and mechanical strength. Suitable for batch heat treatment processes of aluminum profiles, aluminum alloy castings, and aluminum alloy sheets.
Technical Specifications:
Chamber size: 2300mm (D) × 1200mm (W) × 1200mm (H)
Rated heating power: 45kW (3kW × 15 U-shaped stainless steel heating tubes)
Temperature control system: TCW-32A intelligent controller with PID self-tuning, accuracy ±1°C
Circulation system: dual-air-duct horizontal air supply, 4 sets of 750W high-temperature long-shaft motors with centrifugal fans
Insulation layer: 1260 standard alumina silicate fiber, 120mm thickness
English Name:Aging Furnace for Aluminum Alloy
Aliases:Aging Oven, Aluminum Alloy Heat Treatment Furnace
Physical Properties:The equipment features a dual-air-duct circulating horizontal air supply structure, using high-temperature-resistant long-shaft motors driving centrifugal fans to ensure uniform hot air circulation and eliminate temperature dead zones in the furnace chamber. The insulation layer is filled with 1260 standard alumina silicate fiber with a thickness of 120mm, providing excellent thermal insulation. The heating system adopts U-shaped stainless steel tubular heating elements with long continuous service life. Working temperature range is room temperature to 300°C with temperature control accuracy of ±1°C.
Uses:Mainly used for artificial aging treatment of aluminum alloy products. Through precise temperature control heating, it homogenizes the internal structure of aluminum alloy materials, eliminates processing stress, and improves material hardness and mechanical strength. Suitable for batch heat treatment processes of aluminum profiles, aluminum alloy castings, and aluminum alloy sheets.
Technical Specifications:
Chamber size: 2300mm (D) × 1200mm (W) × 1200mm (H)
Rated heating power: 45kW (3kW × 15 U-shaped stainless steel heating tubes)
Temperature control system: TCW-32A intelligent controller with PID self-tuning, accuracy ±1°C
Circulation system: dual-air-duct horizontal air supply, 4 sets of 750W high-temperature long-shaft motors with centrifugal fans
Insulation layer: 1260 standard alumina silicate fiber, 120mm thickness
