实验室简易型反应釜 (CAS No.None)
- 物化性质
- 该设备为模块化设计的实验室级真空反应釜，可在真空或压力环境下实现物料的分散、乳化、均质、混合等工艺过程。允许工作温度最高120°C（可选配高温），可达真空-0.096MPa（正压可选），可处理粘度高达130000CP（超高粘度可选）。工作环境支持密闭、敞开、常压、真空、气体保护、高温、低温等多种条件。接触物料部分采用SUS316L不锈钢+PTFE+硼硅玻璃夹层容器材质，耐腐蚀且易于清洁。
- 技术参数
- 处理量涵盖0.5L、1L、2L、3L、5L等容量规格，SE-1L允许处理量为1000ml，SE-2L为2000ml 搅拌机功率120W，转速18~200rpm（可选超高转速180-2000rpm），桨叶配置锚式刮壁搅拌桨（螺带式可选） 乳化均质机功率500W，转速最高28000rpm，乳化工作头型号20BCS，剪切线速度可达27m/s 反应釜盖开口配置均质机口+投料口+测温口+真空口+3个备用口，真空口外径10mm，夹层进出口径12mm 支架采用铝合金半自动升降设计，升降行程230mm；设备整体尺寸650×650×1500mm，重量50kg，木箱包装
English description（英文原文，共 2138 字符）
Product Name:SE Series Vacuum Reactor
English Name:SE Series Vacuum Reactor
Aliases:SE Type Vacuum Reactor, SE Series Vacuum Reactor System, Compact Vacuum Reactor, Laboratory Vacuum Reactor
Physical Properties:This equipment is a modular laboratory-grade vacuum reactor capable of dispersing, emulsifying, homogenizing and mixing materials under vacuum or pressure conditions. The allowable working temperature is up to 120°C (high-temperature option available), achievable vacuum is -0.096 MPa (positive pressure optional), and processable viscosity up to 130,000 cP (ultra-high viscosity option available). It supports various working environments including sealed, open, atmospheric, vacuum, gas-protected, high-temperature and low-temperature conditions. All wetted parts are made of SUS316L stainless steel + PTFE + borosilicate glass jacketed vessel, providing excellent corrosion resistance and easy cleaning.
Uses:Mainly used for dispersing, emulsifying, homogenizing and mixing of materials in laboratory and small-batch production. It is suitable for fluid R&D and pilot-scale production in chemical, pharmaceutical, food, cosmetic and related industries. The highly modular design allows flexible configuration of optional accessories such as pH meter, conductivity meter, condenser, dropping funnel and aseptic sampling valve to meet customized requirements under various process conditions.
Technical Specifications:
Processing capacity covers 0.5L, 1L, 2L, 3L, 5L options; allowable processing volume is 1000ml for SE-1L and 2000ml for SE-2L
Stirrer power 120W, speed 18-200rpm (optional ultra-high speed 180-2000rpm), equipped with anchor-type scraper stirring blade (ribbon-type optional)
Emulsifying homogenizer power 500W, speed up to 28000rpm, emulsifying head model 20BCS, shear linear velocity up to 27m/s
Reactor lid openings: homogenizer port + feeding port + temperature probe port + vacuum port + 3 spare ports; vacuum port outer diameter 10mm, jacket inlet/outlet 12mm
Aluminum alloy semi-automatic lifting stand with 230mm travel; overall dimensions 650×650×1500mm, weight 50kg, wooden case packaging
English Name:SE Series Vacuum Reactor
Aliases:SE Type Vacuum Reactor, SE Series Vacuum Reactor System, Compact Vacuum Reactor, Laboratory Vacuum Reactor
Physical Properties:This equipment is a modular laboratory-grade vacuum reactor capable of dispersing, emulsifying, homogenizing and mixing materials under vacuum or pressure conditions. The allowable working temperature is up to 120°C (high-temperature option available), achievable vacuum is -0.096 MPa (positive pressure optional), and processable viscosity up to 130,000 cP (ultra-high viscosity option available). It supports various working environments including sealed, open, atmospheric, vacuum, gas-protected, high-temperature and low-temperature conditions. All wetted parts are made of SUS316L stainless steel + PTFE + borosilicate glass jacketed vessel, providing excellent corrosion resistance and easy cleaning.
Uses:Mainly used for dispersing, emulsifying, homogenizing and mixing of materials in laboratory and small-batch production. It is suitable for fluid R&D and pilot-scale production in chemical, pharmaceutical, food, cosmetic and related industries. The highly modular design allows flexible configuration of optional accessories such as pH meter, conductivity meter, condenser, dropping funnel and aseptic sampling valve to meet customized requirements under various process conditions.
Technical Specifications:
Processing capacity covers 0.5L, 1L, 2L, 3L, 5L options; allowable processing volume is 1000ml for SE-1L and 2000ml for SE-2L
Stirrer power 120W, speed 18-200rpm (optional ultra-high speed 180-2000rpm), equipped with anchor-type scraper stirring blade (ribbon-type optional)
Emulsifying homogenizer power 500W, speed up to 28000rpm, emulsifying head model 20BCS, shear linear velocity up to 27m/s
Reactor lid openings: homogenizer port + feeding port + temperature probe port + vacuum port + 3 spare ports; vacuum port outer diameter 10mm, jacket inlet/outlet 12mm
Aluminum alloy semi-automatic lifting stand with 230mm travel; overall dimensions 650×650×1500mm, weight 50kg, wooden case packaging
