实验室喷雾干燥器 (CAS No.None)
- 物化性质
- 型号QFN-6000Y。进口二流体喷雾喷头，雾化效率高；内置全无油空压机，噪音低于60dB。喷雾、烘干及收集系统采用高硼硅耐热玻璃制造，干燥过程在无污染环境下进行。彩色LCD触摸屏显示进/出风口温度、蠕动泵转速、风量和通针频率，支持一键式全自动和手动控制。设有喷嘴清洁器（通针），喷嘴堵塞时自动清除，通针频率可调；配备进风口过滤器和塔壁吹扫装置，物料回收率高。采用PID恒温控制技术，控温精度±1℃，干燥成品颗粒度均匀，95%以上处于同一粒度范围。
- 技术参数
- 通过欧盟CE认证。 进风温度控制范围30℃~300℃，出风温度控制范围30℃~140℃，控温精度±1℃。 蒸发水量1500mL/h~2000mL/h，最大进料量2000mL/h（蠕动泵可调），最小进料量50mL。 平均干燥时间1.0~1.5S。 整机功率3KW/220V，外形尺寸1200mm（高）×650mm（长）×500mm（宽）。
English description（英文原文，共 1678 字符）
Product Name:Laboratory Spray Dryer
English Name:Laboratory Spray Dryer
Aliases:Lab-scale Spray Dryer, Mini Laboratory Spray Dryer
Physical Properties:Model QFN-6000Y. Imported two-fluid spray nozzle with high atomization efficiency; built-in oil-free air compressor with noise below 60 dB. The spray drying and collection system is made of borosilicate heat-resistant glass, ensuring a contamination-free drying process. A color LCD touch screen displays inlet/outlet temperatures, peristaltic pump speed, air volume and needle frequency, supporting one-key automatic and manual control. Equipped with an automatic nozzle cleaner (needle) that clears blockages with adjustable frequency; an inlet air filter and tower wall sweeping device improve material recovery. PID constant temperature control provides ±1°C accuracy; dried powder has uniform particle size with over 95% within the same size range.
Uses:Suitable for producing trace granular powder in laboratories of universities, research institutes, and food, pharmaceutical and chemical enterprises. It has broad applicability to solutions such as emulsions and suspensions, and is especially suitable for drying heat-sensitive materials such as biological products, biopesticides and enzyme preparations.
Technical Specifications:
CE certified.
Inlet air temperature control range 30°C–300°C, outlet air temperature control range 30°C–140°C, temperature control accuracy ±1°C.
Evaporation capacity 1500–2000 mL/h, maximum feed rate 2000 mL/h (adjustable by peristaltic pump), minimum feed volume 50 mL.
Average drying time 1.0–1.5 s.
Total power 3 kW/220 V, dimensions 1200 mm (H) × 650 mm (L) × 500 mm (W).
English Name:Laboratory Spray Dryer
Aliases:Lab-scale Spray Dryer, Mini Laboratory Spray Dryer
Physical Properties:Model QFN-6000Y. Imported two-fluid spray nozzle with high atomization efficiency; built-in oil-free air compressor with noise below 60 dB. The spray drying and collection system is made of borosilicate heat-resistant glass, ensuring a contamination-free drying process. A color LCD touch screen displays inlet/outlet temperatures, peristaltic pump speed, air volume and needle frequency, supporting one-key automatic and manual control. Equipped with an automatic nozzle cleaner (needle) that clears blockages with adjustable frequency; an inlet air filter and tower wall sweeping device improve material recovery. PID constant temperature control provides ±1°C accuracy; dried powder has uniform particle size with over 95% within the same size range.
Uses:Suitable for producing trace granular powder in laboratories of universities, research institutes, and food, pharmaceutical and chemical enterprises. It has broad applicability to solutions such as emulsions and suspensions, and is especially suitable for drying heat-sensitive materials such as biological products, biopesticides and enzyme preparations.
Technical Specifications:
CE certified.
Inlet air temperature control range 30°C–300°C, outlet air temperature control range 30°C–140°C, temperature control accuracy ±1°C.
Evaporation capacity 1500–2000 mL/h, maximum feed rate 2000 mL/h (adjustable by peristaltic pump), minimum feed volume 50 mL.
Average drying time 1.0–1.5 s.
Total power 3 kW/220 V, dimensions 1200 mm (H) × 650 mm (L) × 500 mm (W).
