台式纳米粒子沉积系统 (CAS No.None)
- 物化性质
- 该系统利用磁控溅射在真空环境中产生超纯金属纳米粒子束，可常规且可重复地将非团聚纳米粒子沉积到直径达50毫米的样品上。采用触摸屏全自动配方控制，操作培训仅需10分钟；配有透明室门，装载样品后可在沉积前进行等离子清洗。源材料可在5分钟内快速更换，整个典型工艺循环约30分钟，沉积所得纳米粒子不含碳氢化合物或其他污染物，无需后续干燥或纯化步骤即可直接分析。
- 技术参数
- 样品直径最大可达50毫米。 典型镀膜循环时间约为30分钟。 源材料支持Au、Ag、Cu、Pt、Ir、Ni、Ti、Zr等多种金属及导电材料，由99.999%纯度的固体靶材生成。 更换源材料少于5分钟，且无交叉污染。 全自动触摸屏配方控制，可调节纳米粒子尺寸、分布和层厚度等参数。
English description（英文原文，共 1835 字符）
Product Name:Tabletop Nanoparticle Deposition System
English Name:Tabletop Nanoparticle Deposition System
Aliases:Nanoparticle Deposition System, Tabletop Nanodeposition System, Ultrapure Nanoparticle Coater
Physical Properties:This system utilizes magnetron sputtering in a vacuum environment to generate a beam of ultrapure metal nanoparticles, enabling routine and reproducible deposition of non-agglomerated nanoparticles onto samples up to 50 mm in diameter. It features touchscreen full-automatic recipe control, with operator training requiring only 10 minutes. A transparent chamber door allows sample loading and plasma cleaning before deposition. Source materials can be changed within 5 minutes, and a typical process cycle takes approximately 30 minutes. The deposited nanoparticles are free from hydrocarbons or other contaminants and can be analyzed directly without additional drying or purification steps.
Uses:Widely applied in life sciences and nanomedicine (cancer therapy, drug delivery, antimicrobial, antiviral, biofilm research), graphene (electronics, energy, composites, sensors), photonics (photovoltaics, light harvesting, surface-enhanced Raman scattering), catalysis (fuel cells, photocatalysis, electrochemistry, water/air purification), and sensors (biosensors, optical, electrical, electrochemical, SERS). It is suitable for teaching and shared laboratory use.
Technical Specifications:
Maximum sample diameter: 50 mm.
Typical coating cycle time: approximately 30 minutes.
Source materials: Au, Ag, Cu, Pt, Ir, Ni, Ti, Zr and other conductive materials, generated from solid targets of 99.999% purity.
Source material changeover in less than 5 minutes without cross-contamination.
Fully automated touchscreen recipe control with adjustable nanoparticle size, distribution, and layer thickness.
English Name:Tabletop Nanoparticle Deposition System
Aliases:Nanoparticle Deposition System, Tabletop Nanodeposition System, Ultrapure Nanoparticle Coater
Physical Properties:This system utilizes magnetron sputtering in a vacuum environment to generate a beam of ultrapure metal nanoparticles, enabling routine and reproducible deposition of non-agglomerated nanoparticles onto samples up to 50 mm in diameter. It features touchscreen full-automatic recipe control, with operator training requiring only 10 minutes. A transparent chamber door allows sample loading and plasma cleaning before deposition. Source materials can be changed within 5 minutes, and a typical process cycle takes approximately 30 minutes. The deposited nanoparticles are free from hydrocarbons or other contaminants and can be analyzed directly without additional drying or purification steps.
Uses:Widely applied in life sciences and nanomedicine (cancer therapy, drug delivery, antimicrobial, antiviral, biofilm research), graphene (electronics, energy, composites, sensors), photonics (photovoltaics, light harvesting, surface-enhanced Raman scattering), catalysis (fuel cells, photocatalysis, electrochemistry, water/air purification), and sensors (biosensors, optical, electrical, electrochemical, SERS). It is suitable for teaching and shared laboratory use.
Technical Specifications:
Maximum sample diameter: 50 mm.
Typical coating cycle time: approximately 30 minutes.
Source materials: Au, Ag, Cu, Pt, Ir, Ni, Ti, Zr and other conductive materials, generated from solid targets of 99.999% purity.
Source material changeover in less than 5 minutes without cross-contamination.
Fully automated touchscreen recipe control with adjustable nanoparticle size, distribution, and layer thickness.
