涂装整体式调温机组 (CAS No.None)
- 物化性质
- 采用涡旋式全封闭制冷压缩机，机组由一至五个压缩机组成；配备高效翅片式换热器。采用“小风量大焓差”设计理念，除湿量相同时风量仅为普通除湿机的1/3左右。机组不带风机，需另配风机箱，进风方式分左进风和右进风两种，大型机组可提供上下可拆式结构，分为整体式与分体式，适应不同安装场所。
- 技术参数
- 除湿量≤60kg/h机组采用高效涡旋压缩机，除湿量>60kg/h机组采用高性能无级调载螺杆压缩机，可依气候条件变化实现能量调节。 水侧换热器为壳管式换热器，采用高效换热管；空气侧换热器为铜管套铝翅片式换热器，结构紧凑、耐压好、换热效率高。 蒸发器采用内螺纹铜管和亲水性开窗百页铝鳍片，传热系数较普通蒸发器提高30%。 采用PLC控制，内置PID模拟量调节，控制器采用施耐德、欧姆龙等电器组件，控制精度高，并配置高低压、排气温度、风机、压缩机过载继电器等多重保护装置。 特殊场所蒸发器换热铜管表层采用镀镍防腐处理，蒸发器护板采用高等级不锈钢，机组内壁采用304不锈钢衬板，避免铜铝电腐蚀及弱酸弱碱影响。
English description（英文原文，共 2503 字符）
Product Name:Coating Integrated Temperature-adjusting Unit
English Name:Coating Integrated Temperature-adjusting Unit
Aliases:Coating Water-cooled Fresh Air Duct Dehumidifier, Integrated Temperature-adjusting Dehumidification Unit
Physical Properties:Equipped with hermetic scroll refrigeration compressors, the unit consists of 1 to 5 compressors and features high-efficiency finned-tube heat exchangers. Adopting a "small airflow, large enthalpy difference" design concept, it delivers about 1/3 the airflow of conventional dehumidifiers at the same dehumidification capacity. The unit does not include a fan and requires a separate fan box; air inlet is available in left-hand or right-hand configurations, and large units can be provided with a vertically split structure. Both integral and split types are available to suit different installation sites.
Uses:Primarily used for dehumidification and temperature regulation in water-cooled fresh air duct systems in coating workshops. The temperature-adjusting type combines dehumidification and cooling with adjustable cooling capacity, suitable for places with large heat load fluctuations; the cooling type is suitable for places with large heat loads and no relative humidity requirement.
Technical Specifications:
Units with dehumidification capacity ≤60kg/h use high-efficiency scroll compressors, while units with capacity >60kg/h use high-performance stepless capacity-regulated screw compressors, enabling energy adjustment according to climate conditions.
The water-side heat exchanger is a shell-and-tube type with high-efficiency heat exchange tubes; the air-side heat exchanger is a copper-tube aluminum-finned type, featuring compact structure, good pressure resistance and high heat exchange efficiency.
The evaporator uses internally grooved copper tubes and hydrophilic louvered aluminum fins, increasing the heat transfer coefficient by 30% compared with conventional evaporators.
Equipped with PLC control with built-in PID analog adjustment, using Schneider, OMRON and other electrical components for high control precision, plus multiple protection devices including high/low pressure, discharge temperature, fan and compressor overload relays.
For special environments, the evaporator copper tubes are nickel-plated for anti-corrosion, the evaporator shield uses high-grade stainless steel, and the inner wall is lined with 304 stainless steel to prevent copper-aluminum galvanic corrosion and weak acid/alkali attack.
English Name:Coating Integrated Temperature-adjusting Unit
Aliases:Coating Water-cooled Fresh Air Duct Dehumidifier, Integrated Temperature-adjusting Dehumidification Unit
Physical Properties:Equipped with hermetic scroll refrigeration compressors, the unit consists of 1 to 5 compressors and features high-efficiency finned-tube heat exchangers. Adopting a "small airflow, large enthalpy difference" design concept, it delivers about 1/3 the airflow of conventional dehumidifiers at the same dehumidification capacity. The unit does not include a fan and requires a separate fan box; air inlet is available in left-hand or right-hand configurations, and large units can be provided with a vertically split structure. Both integral and split types are available to suit different installation sites.
Uses:Primarily used for dehumidification and temperature regulation in water-cooled fresh air duct systems in coating workshops. The temperature-adjusting type combines dehumidification and cooling with adjustable cooling capacity, suitable for places with large heat load fluctuations; the cooling type is suitable for places with large heat loads and no relative humidity requirement.
Technical Specifications:
Units with dehumidification capacity ≤60kg/h use high-efficiency scroll compressors, while units with capacity >60kg/h use high-performance stepless capacity-regulated screw compressors, enabling energy adjustment according to climate conditions.
The water-side heat exchanger is a shell-and-tube type with high-efficiency heat exchange tubes; the air-side heat exchanger is a copper-tube aluminum-finned type, featuring compact structure, good pressure resistance and high heat exchange efficiency.
The evaporator uses internally grooved copper tubes and hydrophilic louvered aluminum fins, increasing the heat transfer coefficient by 30% compared with conventional evaporators.
Equipped with PLC control with built-in PID analog adjustment, using Schneider, OMRON and other electrical components for high control precision, plus multiple protection devices including high/low pressure, discharge temperature, fan and compressor overload relays.
For special environments, the evaporator copper tubes are nickel-plated for anti-corrosion, the evaporator shield uses high-grade stainless steel, and the inner wall is lined with 304 stainless steel to prevent copper-aluminum galvanic corrosion and weak acid/alkali attack.
