UHPS型超高压制样系统 (CAS No.None)
- 中文别名
- 超高压制样系统；超高压压片机；XRF超高压压片机
- 英文名称
- UHPS Ultra-high Pressure Sample Preparation System
- 所属类别
- 试剂实验设备
- 物化性质
- 工作温度0~40℃，压力调节精度0.1T；全套模具采用进口碳化钨材质，外层为高韧性特种合金防爆箍；工作腔三周加厚钢板被动防护，观测窗采用双层防弹级耐高压有机玻璃，屏蔽门配备安全锁闭装置，多重防护确保使用安全。
- 技术参数
- 压力规格有200T和320T两种型号，压力可调范围分别为0~200T和0~320T，压力调节精度0.1T 制样效率高，单个样品从加样到出样全程仅需2分钟，无需加入粘结剂或稀释剂 工作温度要求0~40℃，压样尺寸Φ40mm 电源AC 380V±10%, 50Hz, 32A, 3相5线，功率9.5kW 整机尺寸800×800×1900mm + 550×650×1100mm，净重1.6T
English description（英文原文，共 1981 字符）
Product Name:UHPS Ultra-high Pressure Sample Preparation System
English Name:UHPS Ultra-high Pressure Sample Preparation System
Aliases:Ultra-high Pressure Sample Preparation System, Ultra-high Pressure Pellet Press, XRF Ultra-high Pressure Pressing Machine
Physical Properties:Working temperature 0-40°C, pressure adjustment accuracy 0.1T. The complete mold set is made of imported tungsten carbide with an outer layer of high-toughness special alloy anti-burst hoop. The working chamber is passively protected on three sides by thickened steel plates, and the observation window uses double-layer bulletproof high-pressure-resistant plexiglass; the shielding door is equipped with a safety locking device, ensuring multi-level protection for safe operation.
Uses:The UHPS ultra-high pressure sample preparation system solves the problem that some samples cannot be directly pressed into valid pellets by low-pressure pressing or require a binder, enabling true non-destructive, non-interfering, and "dilution-effect-free" sample preparation for XRF analysis. It can also replace the glass bead fusion method, overcoming its disadvantages such as low efficiency, sample dilution effect, high technical requirements, and poor repeatability. It is suitable for XRF analysis sample preparation of various inorganic and organic powder materials including soil, rock, ore, cement, metallurgical powder, catalyst, coal, fly ash, grain, plants, and biological materials.
Technical Specifications:
Two models with pressure ratings of 200T and 320T, adjustable pressure ranges of 0-200T and 0-320T respectively, with a pressure adjustment accuracy of 0.1T
High preparation efficiency: a single sample takes only 2 minutes from loading to ejection, without the need for binders or diluents
Working temperature requirement 0-40°C, pellet size Φ40mm
Power supply AC 380V±10%, 50Hz, 32A, 3-phase 5-wire, power 9.5kW
Overall dimensions 800×800×1900mm + 550×650×1100mm, net weight 1.6T
English Name:UHPS Ultra-high Pressure Sample Preparation System
Aliases:Ultra-high Pressure Sample Preparation System, Ultra-high Pressure Pellet Press, XRF Ultra-high Pressure Pressing Machine
Physical Properties:Working temperature 0-40°C, pressure adjustment accuracy 0.1T. The complete mold set is made of imported tungsten carbide with an outer layer of high-toughness special alloy anti-burst hoop. The working chamber is passively protected on three sides by thickened steel plates, and the observation window uses double-layer bulletproof high-pressure-resistant plexiglass; the shielding door is equipped with a safety locking device, ensuring multi-level protection for safe operation.
Uses:The UHPS ultra-high pressure sample preparation system solves the problem that some samples cannot be directly pressed into valid pellets by low-pressure pressing or require a binder, enabling true non-destructive, non-interfering, and "dilution-effect-free" sample preparation for XRF analysis. It can also replace the glass bead fusion method, overcoming its disadvantages such as low efficiency, sample dilution effect, high technical requirements, and poor repeatability. It is suitable for XRF analysis sample preparation of various inorganic and organic powder materials including soil, rock, ore, cement, metallurgical powder, catalyst, coal, fly ash, grain, plants, and biological materials.
Technical Specifications:
Two models with pressure ratings of 200T and 320T, adjustable pressure ranges of 0-200T and 0-320T respectively, with a pressure adjustment accuracy of 0.1T
High preparation efficiency: a single sample takes only 2 minutes from loading to ejection, without the need for binders or diluents
Working temperature requirement 0-40°C, pellet size Φ40mm
Power supply AC 380V±10%, 50Hz, 32A, 3-phase 5-wire, power 9.5kW
Overall dimensions 800×800×1900mm + 550×650×1100mm, net weight 1.6T
