微机控制电液伺试验机 (CAS No.None)
- 中文别名
- 电液伺服万能试验机；WAW系列微机控制电液伺服万能试验机
- 英文名称
- Microcomputer-controlled Electro-hydraulic Servo Universal Testing Machine
- 所属类别
- 试剂实验设备
- 物化性质
- 油缸下置式、无间隙油膜密封；液压夹紧；活塞行程250mm；圆试样夹持直径φ6-φ40mm（分φ6-φ13mm、φ13-φ26mm、φ26-φ40mm三档），扁试样夹持厚度0-15mm；拉伸空间650mm，压缩空间600mm。
English description（英文原文，共 1228 字符）
Product Name:Microcomputer-controlled Electro-hydraulic Servo Universal Testing Machine
English Name:Microcomputer-controlled Electro-hydraulic Servo Universal Testing Machine
Aliases:Electro-hydraulic Servo Universal Testing Machine, WAW Series Microcomputer-controlled Electro-hydraulic Servo Universal Testing Machine
Physical Properties:Bottom-mounted oil cylinder type with gapless oil film seal; hydraulic clamping; piston stroke 250mm; round specimen clamping diameter φ6-φ40mm (three ranges: φ6-φ13mm, φ13-φ26mm, φ26-φ40mm); flat specimen clamping thickness 0-15mm; tensile space 650mm; compression space 600mm.
Uses:Used for room-temperature tensile, compression, bending, and shear tests on metallic materials, as well as testing of non-metallic materials such as wood, cement, concrete, and rubber.
Technical Specifications:
Test force: 300kN, 600kN, 1000kN, 2000kN (corresponding to WAW-300C/600C/1000C/2000C)
Test force measurement range: 0.2%–100% of maximum test force, indication accuracy ±1%
Displacement measurement resolution: 0.01mm; deformation measurement accuracy ±0.5%
Constant force, constant deformation, and constant displacement control range: 0.4%–100%FS
Implemented standard: GB/T228-2002
English Name:Microcomputer-controlled Electro-hydraulic Servo Universal Testing Machine
Aliases:Electro-hydraulic Servo Universal Testing Machine, WAW Series Microcomputer-controlled Electro-hydraulic Servo Universal Testing Machine
Physical Properties:Bottom-mounted oil cylinder type with gapless oil film seal; hydraulic clamping; piston stroke 250mm; round specimen clamping diameter φ6-φ40mm (three ranges: φ6-φ13mm, φ13-φ26mm, φ26-φ40mm); flat specimen clamping thickness 0-15mm; tensile space 650mm; compression space 600mm.
Uses:Used for room-temperature tensile, compression, bending, and shear tests on metallic materials, as well as testing of non-metallic materials such as wood, cement, concrete, and rubber.
Technical Specifications:
Test force: 300kN, 600kN, 1000kN, 2000kN (corresponding to WAW-300C/600C/1000C/2000C)
Test force measurement range: 0.2%–100% of maximum test force, indication accuracy ±1%
Displacement measurement resolution: 0.01mm; deformation measurement accuracy ±0.5%
Constant force, constant deformation, and constant displacement control range: 0.4%–100%FS
Implemented standard: GB/T228-2002
