微机控制电子拉力试验机 (CAS No.None)
- 中文别名
- 电子拉力试验机；WDW系列电子万能试验机
- 英文名称
- Microcomputer-controlled Electronic Tensile Testing Machine
- 所属类别
- 试剂实验设备
- 物化性质
- 采用微机控制、伺服电机驱动，配备高精度负荷传感器及变形测量装置，可实现力、变形、位移三闭环控制，并能无冲击切换。适用于金属、非金属材料的拉伸性能测试，可求取最大拉力、抗拉强度、屈服强度、断裂伸长率等参数。
- 技术参数
- 最大试验力为200kN/300kN，负荷测量示值相对误差≤±0.5%，试验力分辨力为1/±300000FS。 变形分辨力为变形量的1/±300000，示值误差在±0.5%以内；位移分辨力为0.015μm。 力控速率调节范围0.005~5%FS/S，设定值误差在±1%以内；应变速率调节范围0.02~5%FS/S，速率<0.05%FS时误差±2%，速率≥0.05%FS时误差±0.5%。 十字头移动速率0.001~300mm/min，横梁移动行程约1250mm（不含夹具），有效试验跨度610mm，均可定制。 电源电压AC 380V±10%，50Hz，整机功率约3.0kW；主机外形尺寸约1050×750×2400mm，重量约1800kg。
English description（英文原文，共 1664 字符）
Product Name:Microcomputer-controlled Electronic Tensile Testing Machine
English Name:Microcomputer-controlled Electronic Tensile Testing Machine
Aliases:Electronic Tensile Tester, WDW Series Electronic Universal Testing Machine
Physical Properties:This machine is controlled by a microcomputer and driven by a servo motor, equipped with a high-precision load cell and deformation measuring device. It realizes closed-loop control of force, deformation, and displacement with bump-free switching. It is suitable for tensile testing of metallic and non-metallic materials, and can obtain maximum tensile force, tensile strength, yield strength, and elongation at break.
Uses:Mainly used for tensile mechanical performance testing of metal, non-metal, and composite material specimens, determining tensile strength, yield strength, elongation and other indicators. It is a common equipment for material inspection, quality control, and scientific research.
Technical Specifications:
Maximum test force: 200kN/300kN; load measurement indication relative error ≤±0.5%; test force resolution: 1/±300000FS.
Deformation resolution: 1/±300000 of deformation, indication error within ±0.5%; displacement resolution: 0.015μm.
Force control rate adjustment range: 0.005~5%FS/S, setting error within ±1%; strain rate adjustment range: 0.02~5%FS/S, error within ±2% when rate <0.05%FS, and within ±0.5% when rate ≥0.05%FS.
Crosshead speed: 0.001~300mm/min; beam travel: approximately 1250mm (excluding grips); effective test width: 610mm; all customizable.
Power supply: AC 380V±10%, 50Hz, about 3.0kW; dimensions: approximately 1050×750×2400mm; weight: about 1800kg.
English Name:Microcomputer-controlled Electronic Tensile Testing Machine
Aliases:Electronic Tensile Tester, WDW Series Electronic Universal Testing Machine
Physical Properties:This machine is controlled by a microcomputer and driven by a servo motor, equipped with a high-precision load cell and deformation measuring device. It realizes closed-loop control of force, deformation, and displacement with bump-free switching. It is suitable for tensile testing of metallic and non-metallic materials, and can obtain maximum tensile force, tensile strength, yield strength, and elongation at break.
Uses:Mainly used for tensile mechanical performance testing of metal, non-metal, and composite material specimens, determining tensile strength, yield strength, elongation and other indicators. It is a common equipment for material inspection, quality control, and scientific research.
Technical Specifications:
Maximum test force: 200kN/300kN; load measurement indication relative error ≤±0.5%; test force resolution: 1/±300000FS.
Deformation resolution: 1/±300000 of deformation, indication error within ±0.5%; displacement resolution: 0.015μm.
Force control rate adjustment range: 0.005~5%FS/S, setting error within ±1%; strain rate adjustment range: 0.02~5%FS/S, error within ±2% when rate <0.05%FS, and within ±0.5% when rate ≥0.05%FS.
Crosshead speed: 0.001~300mm/min; beam travel: approximately 1250mm (excluding grips); effective test width: 610mm; all customizable.
Power supply: AC 380V±10%, 50Hz, about 3.0kW; dimensions: approximately 1050×750×2400mm; weight: about 1800kg.
